Rackmount DVI SUN USB KVM Drawer
The RACKMUX® SUN USB KVM Drawer combines a rackmount LCD monitor, SUN USB keyboard and 3-button trackball mouse or touchpad in a space-saving 1RU industrial strength drawer. It is available with a forward-folding 17" Active Matrix LCD flat panel DVI monitor.
Features & Applications:
- Forward-folding 17" Active Matrix LCD flat panel DVI monitor.
- Supports SUN-compatible 1152x900 resolution.
- Tilt LCD up and back to adjust to any comfortable viewing angle to 120°.
- Torque-friction hinges-monitor does not wobble, spring, or slam shut.
- Compact, heavy-duty tactile keyboard.
- Available with 17-key numeric keypad or large wrist-rest.
- Drawer locks into place when open to prevent it from sliding in and out of the rack.
- Available with optional mounting bracket for two-post style telco rack.
- Rugged steel construction with durable powder coat finish.
- LCD auto-shutoff in closed position.
- Internal cable arm provides proper cable management for sliding the drawer open and closed.
- Equipped with On Screen Display (OSD).
- Front panel security lock.
- Front panel USB port to connect an external USB device, such as a flash drive.
- Available with Sunlight Readable monitor – call an NTI Product Consultant for more information.
Specifications:
Host Interface
- Compatible with USB-enabled SUN, Windows, Linux, Apple, IBM, and HP computers with single link DVI-D video.
- One female DVI-I and one female USB Type B connectors.
- Multiplatform support: Windows 2000/XP/Vista/Server 2000/2003/2008, Solaris, Linux, FreeBSD, and MAC OS 9/10.
Monitor
- Forward-folding 17" Active Matrix LCD flat panel DVI monitor.
- 1280x1024 video resolution.
- Supports SUN-compatible 1152x900 resolution.
- Tilt: up to 120°.
- Frequency:
- Horzontal: 31 to 80 KHz
- Vertical: 55 to 76 Hz.
- OSD controls for brightness, contrast, phase, pitch, Horz- and Vert-center alignment, zoom and color adjustment.
- 300 nits brightness and 500:1 contrast ratio typical.
- Supports DDC1 and DDC2B protocols.
Devices
- Keyboard available in multiple languages: English(US), English(UK), German, Italian, French, and Spanish.
- RACKMUX-DS17-T: 97-key (US) or 98-key (UK, German, Italian, French, Spanish), SUN-compatible keyboard with wrist-pad.
- RACKMUX-DS17-NT: 114-key (US) or 115-key (UK, German), SUN compatible keyboard with numeric keypad.
- Supports SUN keys including STOP, CUT, PASTE, COMPOSE, COPY, HELP, OPEN, UNDO, and PROPS.
- Three button trackball mouse.
- Front panel USB 1.1 port to connect external USB devices.
- Female USB Type A connector.
MTBF
- RACKMUX-DS17-T: 40,530 hrs.
Cables
- 6.5-foot single link DVI-D male to male cable included.
- 6-foot USB Type A male to USB Type B male cable included.
- 6-foot power supply cable included.
Power
- 110 or 220 VAC at 50 or 60 Hz via IEC connector.
- Power Consumption: 30W
- Maximum Inrush Current: 30A
Environmental
- Operating temperature: 32°F to 104°F (0°C to 40°C).
- Storage temperature: -4°F to 140°F (-20°C to 60°C).
- Operating and Storage Relative Humidity: 20 to 90% non-condensing RH.
Dimensions
- WxDxH (Inches): 19x23.9x1.75.
- Weight: 26 lbs.
- Drawer is adjustable to various rack depths from 24" deep to 39" deep.
- Drawer locks into place when open to prevent it from sliding in and out of the rack.
- Rack ears are available for two post style telco rack mounting, select part number RL-T15-TEL.
Regulatory Approvals
Warranty
|
