- Compliance with the newest Intel standard ATX 12V V2.3
- Support dual +12V1 and +12V2 outputs for higher power usage
- SATA Connector x 6
- Two-year warranty
- High reliability (MTBF > 100,000 hours
- Protection design (OVP/OCP/OPP/SCP)
- More than 70% better efficiency at typical load operation
- 6+2Pin PCI-e Connector x 2
||Intel Form Factor ATX 12V V2.3
||Standard ATX 150 x 140 x 86 (mm)
||110 ~ 115V / 220 ~ 230V
||8A@115Vac / 6.3A@230Vac
|Input Frequency Range
||47 ~ 63 Hz
|Power Good Signal
||100 ~ 500 ms
|Hold Up Time
||> 17 ms
||OVP / OPP / SCP
||5~40°C Nominal Input Voltage
||Nemko / TUV / UL / CE / BSMI / FCC / GOST / C-tick
||M/B 20+4 Pin x 1
CPU 4+4 Pin x 1
PCI-E 6+2 Pin x 2
4 Pin Peripheral x 3
SATA x 3
4 Pin Floppy x 1
