Essentials |
Product Collection |
Intel® SSD 6 Series |
Code Name |
Products formerly Keystone Harbor |
Capacity |
2 TB |
Status |
Launched |
Launch Date |
Q1'21 |
Lithography Type |
3D4 QLC |
Use Conditions |
PC/Client/Tablet |
Performance Specifications |
Sequential Bandwidth - 100% Read (up to) |
3500 MB/s |
Sequential Bandwidth - 100% Write (up to) |
2700 MB/s |
Random Read (8GB Span) (up to) |
310000 IOPS |
Random Write (8GB Span) (up to) |
340000 IOPS |
Power - Active |
80 mW |
Power - Idle |
25 mW |
Reliability |
Vibration - Operating |
2.17 GRMS (5-700 Hz) Max |
Vibration - Non-Operating |
3.13 GRMS (5-800 Hz) Max |
Shock (Operating and Non-Operating) |
1,000 G (Max) at 0.5 msec |
Operating Temperature Range |
0°C to 70°C |
Operating Temperature (Maximum) |
70 °C |
Operating Temperature (Minimum) |
0 °C |
Endurance Rating (Lifetime Writes) |
740 |
Mean Time Between Failures (MTBF) |
1.6 million hours |
Uncorrectable Bit Error Rate (UBER) |
<1 sector per 10^15 bits read |
Warranty Period |
5 yrs |
Package Specifications |
Form Factor |
M.2 22 x 80mm |
Interface |
PCIe 3.0 x4, NVMe |
Advanced Technologies |
Enhanced Power Loss Data Protection |
No |
Hardware Encryption |
AES 256 bit |
High Endurance Technology (HET) |
No |
Temperature Monitoring and Logging |
No |
End-to-End Data Protection |
Yes |
Intel® Smart Response Technology |
Yes |
Intel® Rapid Start Technology |
Yes |
Intel® Remote Secure Erase |
No |
