Archer C20, IEEE 802.11b/g/n, 802.11ac/n/a, Dual-Band 2.4 / 5GHz, 300 / 433 Mbps, 4xRJ45, Wireless Router

SKU: 11843806

Manufacturer: TP-LINK

MPN: ARCHER C20

Availability: Available


Price: $37.51
or as low as $1/month
Quantity:
  • Upgrade your Wi-Fi to connect newer AC devices
  • Delivers reliable AC750 Wi-Fi over dual 2.4 GHz (300 Mbps) and 5 GHz (433 Mbps) bands
  • Strong coverage and connectivity with three high-quality antennas
  • Easily set up and manage your Wi-Fi using the intuitive Tether App
HARDWARE FEATURES
Interface 4 10/100Mbps LAN ports
1 10/100Mbps WAN port
Button WPS/Wi-Fi Button
Reset Button
Power On/Off Button
External Power Supply 9V/0.6A(EU), 9V/0.85A(US)
Dimensions ( W x D x H ) 9.1 x 5.7 x 1.4 in. (230 x 144 x 35mm)
Antenna 2 × 2.4GHz Antennas
1 × 5GHz Antenna
WIRELESS FEATURES
Wireless Standards IEEE 802.11ac/n/a 5GHz
IEEE 802.11b/g/n 2.4GHz
Frequency 2.4GHz and 5GHz
Signal Rate 5GHz: Up to 433Mbps
2.4GHz: Up to 300Mbps
Reception Sensitivity 5GHz:
11a 54M: -76dBm; 11ac VHT20 MCS8: -71dBm;
11ac VHT40 MCS9: -66dBm; 11ac VHT80 MCS9:
-62dBm
2.4GHz:
11g 54M: -76dBm11n; HT20 MCS7: -73dBm;
11n HT40 MCS7: -71dBm
Wireless Functions Enable/Disable Wireless Radio, WDS Bridge, WMM, Wireless Statistics
Wireless Security 64/128-bit WEP,WPA / WPA2,WPA-PSK/ WPA2-PSK encryption
Transmission Power CE:
<20dBm(2.4GHz)
<23dBm(5GHz)
SOFTWARE FEATURES
Quality of Service WMM, Bandwidth Control
Management Access Control
Local Management
Remote Management
Port Forwarding Virtual Server, Port Triggering, UPnP, DMZ
Dynamic DNS DynDns, Comexe, NO-IP
VPN Pass-Through PPTP, L2TP, IPSec
Access Control Parental Control, Local Management
Control, Host List,
Access Schedule, Rule Management
Firewall Security DoS, SPI Firewall, IP Address Filter/Domain Filter, IP and MAC Address Binding
Protocols Supports IPv4 and IPv6
Guest Network 2.4GHz guest network × 1
5GHz guest network × 1
OTHERS
Certification CE, RoHS
Package Contents AC750 Wireless Dual Band Router Archer C20
Power Adapter
RJ45 Ethernet Cable
Quick Installation Guide
Box Dimensions (W X D X H) 14 x 8.8 x 2.7 in. (357x223x68mm)
System Requirements Microsoft Windows XP/Vista/7/8/8.1/10, MAC OS, UNIX or Linux
Internet Explorer, Firefox, Chrome, Safari or other Java-enabled browsers
Cable or DSL or Fiber Modem/Terminal
Subscription with an Internet Service Provider (for Internet access)
Environment Operating Temperature: 0°C~40 °C (32 ?~104?)
Storage Temperature: -40°C~70 °C (-40 ?~158?)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
