Define 7 Nano, Tempered Glass, No PSU, Mini-ITX, Black, Mini Tower Case

Quantity:
  • SKU: 15108542
  • Manufacturer: Fractal Design
  • MPN: FD-C-DEF7N-02
  • Availability: TEMPORARILY OUT OF STOCK
Starting At
$144.25
Quantity:
Define 7 Nano, Tempered Glass, No PSU, Mini-ITX, Black, Mini Tower Case

Re-defining precision.

The Define 7 Nano re-defines precision, bringing clean design and a host of features from its larger siblings to a minimized form factor. The compact yet spacious interior can accommodate all Mini ITX and Mini-DTX motherboards, and there’s room for a GPU up to 306 mm with a 25 mm front fan, making it a highly versatile Nano case.

  • Compact yet spacious interior accommodates any Mini ITX and Mini-DTX motherboard
  • Room for GPU up to 306 mm with a 25 mm front fan
  • Flexible storage option supporting one 3.5” drive and three 2.5”
  • Top panel effortlessly swaps from solid steel to filtered ventilation
  • Removable top fan bracket design opens up to fully expose the case interior for effortless installation and cable routing
  • Silence-optimized construction with industrial sound-damped front, top, and side panels
  • Brushed aluminum front and top-latching side panels offer a clean sophisticated look
  • Install up to 6 x 120 mm or 3 x 140 mm fans (140mm top fan needs to be slim max 15mm, 1 x 120 mm and 1 x 140 mm Dynamic X2 fans included)
  • Five front USB ports including one USB Type-C with fast charging support and speeds up to 10Gbps
  • Bridgeless expansion slots ensure obstruction-free connections for easier installation and hookup
  • Ventilated PSU shroud with two-part modular air duct for increased GPU airflow and radiator support
  • Easy-to-clean high airflow nylon filters on the front, top and base with full PSU coverage and convenient front access
  • Integrated cable guides with cable straps further simplify cable management behind the board
Specifications
3.5"/2.5" drive mounts 1 (included)
2.5" drive mounts 3 (2 included)
Expansion slots 2
Front interface 1x USB 3.1 Gen 2 Type-C, 2x USB 3.0, 2x USB 2.0, Audio
Total fan mounts 6x 120 mm or 3x 140 mm (top 140mm fan mount requires 15 mm slim fans)
Front fan 2x 120/140 mm (1x Dynamic X2 GP-14 included)
Top fan 2x 120 or 1x 140 slim fan (max 15 mm)
Rear fan 1x 120 mm (1x Dynamic X2 GP-12 included)
Bottom fan 1x 120 mm (requires removal of HDD tray)
Dust filters Top, Front, Bottom and PSU
Cable routing space 15-25 mm
Cable routing grommets Yes
Fixed cable ties Yes
Tool-less push-to-lock Both side panels
Captive thumbscrews SSD and PSU brackets
Left side panel Industrial sound-damped steel (Solid) or Tinted Glass panel (TG)
Right side panel Industrial sound-damped steel
Compatibility
Motherboard compatibility Mini ITX / Mini-DTX
Power supply type ATX
Front radiator 120/240, 140/280 mm (316 mm max height, 146 mm max width, 280 mm recommended in “push” configuration for easier fit)
Top radiator N/A
Rear radiator 120 mm
Bottom radiator N/A
PSU max length 165 mm recommended (200 mm without HDD-tray and modular air duct)
GPU max length 331 mm, 306 mm with front fan
GPU max thickness 57 mm / 2.8 slot
CPU cooler max height 167 mm
Dimensions
Case dimensions (LxWxH) 399 x 205 x 361 mm
Case dimensions w/o feet/protrusions/screws 390 x 205 x 345 mm
Net weight 7.1kg (TG) / 7.2kg (solid)
Package dimensions (LxWxH) 417 x 277 x 471 mm
Gross weight 8.5kg (TG) / 8.6 (solid)
Other
Package contents Define 7 Nano computer case, User manual, Accessory box, Ventilated top panel
SKU Black Solid: FD-C-DEF7N-01, Black TG Light Tint: FD-C-DEF7N-02
EAN Black Solid: 7340172702832, Black TG Light Tint: 7340172702849
UPC Black Solid: 843276102838, Black TG Light Tint: 843276102845
JAN Black Solid: 4537694282314, Black TG Light Tint: 4537694282321
Warranty 2 Years
