Define Mini C, No PSU, microATX, Black, Mini Tower Case

Quantity:
  • SKU: 10902228
  • Manufacturer: Fractal Design
  • MPN: FD-CA-DEF-MINI-C-BK
  • Availability: TEMPORARILY OUT OF STOCK
Starting At
$97.73
Quantity:
  • Define Series sound dampening with ModuVent™ technology for silent operation in a compact micro ATX form factor
  • Optimized for high airflow and silent computing
  • Side and front panels are lined with industrial-grade sound dampening material
  • Flexible storage options with room for up to 5 drives
  • Comes with two preinstalled Fractal Design Dynamic X2 GP-12 120 mm fans optimized to deliver maximum airflow while still maintaining a low noise level
  • Equipped with 5 PCI expansion slots for powerful dual GPU setups.
  • Open air designed interior creates an unobstructed airflow path from the front intake to the rear exhaust
  • Easy-to-clean high airflow nylon filters on the front and base with full PSU coverage and front access for convenience.
  • Includes optional top filter to prevent dust buildup when ModuVent is removed for additional fan slots.
  • Power supply shroud conceals drive cage and excess cabling for an even quieter and cleaner looking interior free of airflow obstructions 
Specifications
3.5" or 2.5" Drive capacity 2
Dedicated 2.5" drive capacity 3 (Maximum 2.5" drive thickness is 10mm)
Expansion slots 5
Front ports 2 USB 3.0, Audio in/out, Power button with LED, HDD activity LED, Reset button
Total fan mounts 5
Front fan 3x 120 mm or 2x 140 mm (1x Dynamic X2 GP-12 included)
Top fan 2x 120/140 mm
Rear fan 1x 120 mm (1x Dynamic X2 GP-12 included)
Bottom fan 1x 120 mm
Dust filters Bottom fan + PSU, Front fans, Top panel (optional)
Cable routing grommets Yes
Fixed velcro straps Yes
Captive thumbscrews Both side panels, SSD brackets
Left side panel Clear transparent window
Right side panel Industrial sound-dampened steel
Compatibility
Power supply type ATX
Motherboard compatibility Micro ATX, ITX
Front radiator 280, 240, 140 or 120 mm, max width 144 mm
Top radiator 240 or 120 mm, max component height on motherboard 40 mm
Rear radiator 120 mm, max width 125 mm
PSU max length 175 mm
GPU max length 315 mm with front fans mounted
CPU cooler max height 168 mm
Cable routing space 15 - 35 mm
Dimensions
Case dimensions (LxWxH) 399 x 210 x 399 mm
Case dimensions - with feet/protrusions/screws 413 x 210 x 412 mm
Net weight 6.3 kg
Package dimensions (LxWxH) 502 x 290 x 484 mm
Package weight 7.7 kg
