- Compact 15" Depth
- 1.6mm Steel Body Chassis
- Shock Absorbing Drive Cage
- Front Access USB2.0 x2
- 120mm x1 Cooling Fan
- Removable Air Filter
- Fan and Temperature Monitor Option
- Industrial Keylock Bezel
- 500W Redundant Power Supply
Model Number | E-40-50R8PD2 |
RoHS Compliance Version | Yes |
Form factor | 4 U |
Standard Drive Bays | 3.5" Drives: 1
3.5" Drive (internal): 2 5.25" Drives: 2 |
Indicators | LEDs for Power ON/OFF, HDD, Fan & Alarm |
Switches | Power ON/OFF, System & Alarm Reset |
Expansion Slots | 7 |
Security | Front Bezel |
Material of Front Bezel | 1.6mm SECC Zinc-Coated Steel |
Material of Handle | 1.6mm SECC Zinc-Coated Steel |
Material of Main Chassis | 1.6mm SECC Zinc-Coated Steel |
Color of Front Bezel | Black |
Color of Main Chassis | Black |
Front Connector | Front USB 2.0 x 2 Connector |
Air Filter | Removable & Washable |
Motherboard Size | 12 x 9.6 (ATX, microATX) |
Cooling Fan | 1x120mm |
Dimensions (WxHxD) | 19.00" x 6.97" x 15.00"
482.6 mm x 177.0 mm x 381.0 mm |
