E1659FWU, 15.6" TN, 1366 x 768 (HD), 12 ms, 60Hz, Portable Monitor

  • SKU: 8279939
  • Manufacturer: AOC
  • MPN: E1659FWU
  • Availability: USUALLY SHIPS WITHIN 1-3 WEEKS
Starting At
E1659FWU, 15.6" TN, 1366 x 768 (HD), 12 ms, 60Hz, Portable Monitor

The AOC USB monitor e1659Fwu, also known as the myConnect, is an extremely versatile 15.6-inch (39.6 cm) monitor targeted at users of netbooks, notebooks or other portable computers. Thanks to the DisplayLink technology utilised, a single USB 3.0 cable connects the ultra-slim (0.09" / 22.9 mm) WXGA model with a notebook, transmitting data and providing power. Users can enjoy a dual monitor set-up in an instant. The display comes with a sleeve, which makes it even easier to carry the lightweight (1.2 kg) display. For even more convenience, the monitor stand can be rotated, allowing to choose between a landscape or portrait orientation (pivot) – useful for desktop presentations, document viewing, texts or mail clients. If you want to enhance your workspace and efficiency wherever you go, the e1659Fwu is the right choice!

Screen detail
Resolution 1366x768
Refresh rate 60Hz
Response time 5 ms
Panel TN
Backlight WLED
Aspect Ratio 16:09
Brightness (typical) 200 cd/m²
Contrast (dynamic) 20M:1
Contrast (static) 500:1
Pixel Pitch (H) (V) 252
Diagonal (inch) 15.6 inch
Active Screen Area (HxW) 344.23 x 193.54 mm
Viewing Angle (CR10) 90/60
Display Colours 16.7 Million
OSD languages EN, FR , ES, PT, DE, IT, NL, SE, FI, PL ,CZ, RU, KR, CN (T), CN (S), JP
Swivel 0 °
Powersupply External
Power Consumption On <7 watt
Power Consumption Off 0 watt
Power Consumption Standy 0.03 watt
Product dimensions incl base mm x mm x mm 369.8 x 219.14 x 22.2 mm
Carton dimensions mm x mm x mm 442x85x295 mm
Net weight excl package kg 1.2 Kg
Gross weight incl package kg 1.7 Kg
Warranty period 3 Years
MTBF 50.000 hours
UPC Code 685417062485
TUV Bauart
PVC brf free
Rohs compliant
EUP compliant
