| Reservoir: |
| Dimensions with the attached pump (W x D x H): |
312 x 76 x 142mm |
| Reservoir volume: |
~250ml |
| D-RGB LED count: |
9 |
| D-RGB cable length: |
800mm |
| D-RGB connector standard |
3-pin (+5V, Data, Blocked, Ground) |
| Pump Motor Technical Specifications: |
| Motor: |
Electronically commuted spherical motor |
| Rated voltage: |
12V DC |
| Power consumption: |
30W |
| Maximum head pressure: |
3.9m |
| Maximum flow: |
1500L/h |
| Maximum liquid temperature: |
60°C |
| Cable color: |
Black |
| Power connector: |
SATA power and 4-Pin PWM FAN connector |
| Operational Regime: |
| PWM duty cycle: |
~ 20-100% |
| Default behavior: |
Runs at 100% duty cycle when no PWM feedback signal is present |
