General | |
Function | BA |
Drawing | |
Style Number | ePBZ75 |
Part Number | ePBZ75 |
Product Code | 50005 |
Availability | Top Sellers 0-2 week lead time |
U Height | 0 |
Physical | |
Dimensions (H x W x D, inches) | Box: 24.4 x 5.51 x 2.75 Unit: 24 x 1.5 x 1.5 |
Mounting Style | Vertical |
Form factor | 0U |
Input | |
Max kW | 1.44 |
Plug |
(1) NEMA 5-15P
|
Cable Length (ft) | 15 |
Voltage | 1-Phase 100-120 |
Current | 15A |
Current Monitoring | None |
Phase | Single-Phase |
Frequency | 47-63 Hz |
Output | |
Outlets |
(14) NEMA 5-15R
|
Circuit Breakers | None |
Protection & Filtering | |
Spike/Surge Suppression | None |
EMI/RFI Filter | None |
Standards | |
Approvals | UL Listed |
