ET500-B, 80 PLUS Bronze 500W, No Modular, ATX Power Supply
Quantity:
- SKU: 13621431
- Manufacturer: SILVERSTONE
- MPN: ET500-B
- Availability: USUALLY SHIPS WITHIN 1-3 WEEKS
Starting At
$64.39
As low as $5.37/ Month*
- High efficiency with 80 PLUS Bronze certification
- 24/7 continuous power output with 40? operating temperature
- Class-leading single +12V rail
- Silent running 120mm fan with 18 dBA
- PCIe 8pin and PCIe 6pin connectors support
- All-black flat cables design
| Model No. | SST-ET500-B | ||||
| Max. DC Output | 500W | ||||
| Power density | 277W per liter | ||||
| Load Range | |||||
| +3.3V | +5V | +12V | +5VBS | -12V | |
| Max.(Amps) | 18A | 16A | 38A | 2.5A | 0.3A |
| Peak (Amps) | / | / | / | 3.0A | / |
| Min.(Amps) | 0.3A | 0.5A | 1.0A | 0.0A | 0.0A |
| Range (%) | ±5% | ±5% | ±5% | ±5% | ±10% |
| Line Reg.(%) | ±1% | ±1% | ±1% | ±1% | ±1% |
| Ripple(mVp-p) | 50mV | 50mV | 120mV | 50mV | 120mV |
| Color | Black (Lead-Free Paint) | ||||
| Combined +3.3V & +5V | 110W | ||||
| Combined +12V | 456W | ||||
| Input Voltage | 103 ~ 254 Vrms | ||||
| Input Frequency Range | 47Hz ~ 63Hz | ||||
| PFC | Active PFC(PF>0.9 at full load) | ||||
| Efficiency | 82% ~ 85% at 20% ~ 100% loading | ||||
| MTBF | 100,000 hours | ||||
| Operating temperature | 0°C ~ 40°C | ||||
| Protection |
Over Current Protection Over Power Protection Over Voltage Protection Short Circuit Protection Over Temperature Protection |
||||
| Connectors |
1 x 24 / 20-Pin motherboard connector(500mm) 1 x 8 / 4-Pin EPS / ATX 12V connector(750mm) 2 x 8 / 6-Pin PCIE connector("500mm / 150mm") 6 x SATA connector("500mm / 150mm / 150mm" x 2) 3 x 4-Pin Peripheral connector(500mm / 150mm / 150mm) 1 x 4-Pin Floppy connector(500mm / 150mm / 150mm / 150mm) |
||||
| Cooling System | Single 120mm silent fan | ||||
| Form factor | ATX | ||||
| Noise Level | 18dBA minimum | ||||
| Dimension |
150 mm (W) x 86 mm (H) x 140 mm (D) 5.91" (W) x 3.39" (H) x 5.51" (D) |
||||
| Weight | 1.47 kg | ||||
| Certification | 80 PLUS Bronze | ||||
| Other |
GPU Support list Compatible with ATX12V v2.4 |
||||
