Hydro PTM X PRO HPT3-1000M Gen5, 80 PLUS Platinum 1000W, ECO Mode, Fully Modular, ATX Power Supply
Quantity:
- SKU: 15912244
- Manufacturer: FSP GROUP
- MPN: HPT3-1000M-G5
- Availability: USUALLY SHIPS WITHIN 3-5 DAYS
Starting At
$286.72
Hydro PTM X PRO HPT3-1000M Gen5, 80 PLUS Platinum 1000W, ECO Mode, Fully Modular, ATX Power Supply
FSP HYDRO PTM X PRO series features 12VHPWR Connector and complies ATX3.0 with PCIe 5.0 is fully modular low noise power supplies with 130mm length deliver up to 1200W and high efficiency 80 Plus® Platinum power to your PC build. With the half-bridge LLC topology circuit design and 450V, 105°C Japanese main bulk capacitors, PC parts receive premium power input from HYDRO PTM X PRO series power supplies. Besides, for demanding PC upgrades, you can have all the connections needed from HYDRO PTM X PRO series power supplies
- Complies with ATX12V V3.0 & EPS12V V2.92
- Efficiency ? 92% @ typical load
- Active PFC ? 0.9
- 450V, 105°C Japanese bulk capacitors
- Japanese electrolytic capacitors
- Industrial-grade design with conformal coating application
- +12V single-rail design
- +5V & 3.3V DC to DC module design
- Eco semi-fanless fan control switch
- 120mm fluid dynamic bearing (FDB) fan
- Fully modular cabling design
- Black flat cables
- Changeable side stickers for DIY enthusiasts and gamers
- Complete protection: OCP/OVP/OPP/SCP/OTP
| Model | HPT3-1000M,Gen5 |
| Rated Output Power | 1000W |
| Form Factor | ATX |
| 80 PLUS Certification | Platinum |
| Input Voltage | 100-240V ; 200-240V |
| Input Current | 13-6A ; 6A |
| Input Frequency | 50-60Hz |
| PFC | Active PFC |
| Efficiency | 92% |
| Fan Type | FDB fan, 120mm |
| Dimensions(L x W x H) | 130×150×86 mm |
| Operation Temp. | 100,000 Hrs |
| Protection | OCP, OVP, OPP, SCP, OTP |
