To meet the needs of enthusiasts and professionals building high performance but quiet PCs or liquid cooled systems, SilverStone created the Kublai KL07, a silent tower chassis with elegant styling and high-tech features. It has many modern features such as front USB Type-C connector, power supply / drive cover, convenient tool-less drive trays, and smart backside cable routing design. The KL07 not only has highly flexible space for installing all popular core components, it also has incredible support for a myriad of cooling configurations. There are six total 120 / 140mm fan slots around the case with maximum radiator support of up to 360mm. KL07 in operation can also be eerily silent as it has wave-patterned foam applied on the inside to reduce perceived noise while its front-side intake vents are designed to redirect soundwave with a quick access dust filter helping to further dampen noise output from the front side.
Model No. | SST-KL07B (black) | |
Material | Plastic front panel, steel body | |
Motherboard | ATX ( up to 12" x11") , Micro-ATX | |
Drive bay | External | -- |
-- | ||
Internal | 3.5" x 3 (compatible with 2.5") , 2.5" x 3 | |
Cooling system | Front | 3 x 120 / 140mm fan slot (2 x 140mm intake fan included) |
Rear | 1 x 120 / 140mm fan slot (1 x 140mm exhaust fan included) | |
Side | -- | |
Top | 2 x 120 / 140mm fan slot | |
Bottom | -- | |
Internal | -- | |
Expansion slot | 7 | |
Front I/O port | USB 3.0 x 2, Type-C* x 1
Audio x 1 MIC x 1 |
|
Power supply | Optional PS2(ATX) | |
Expansion card | Compatible up to 15.3" (388mm) in length, width restriction –6.5" (165mm) | |
Limitation of CPU cooler | 163 ~ 172mm** | |
Limitation of PSU | 140 ~ 200mm*** | |
Net weight | 7.7kg | |
Dimension | 222mm (W) x 510mm (H) x 467mm (D), 52.8 Liters
8.74" (W) x 20.08" (H) x 18.39" (D), 52.8 Liters |
