Level 20 XT Tempered Glass, No PSU, E-ATX, Black, Cube Case

SKU: 12331201

Manufacturer: THERMALTAKE

MPN: CA-1L1-00F1WN-00

Availability: Available


Price: $290.93
or as low as $9/month
Quantity:

Thermaltake Level 20 XT Cube Chassis

Thermaltake is thrilled to present the latest TT Premium product line – Level 20 Series which commemorates 20 years of dedication to the PC industry. Under this product line is the new Level 20 Series – Level 20 XT.
Level 20 XT is a cube case specially designed to show off custom liquid cooling systems. The level 20 XT has a unique flat motherboard design that puts components on display from any angle, and a chamber design that separates cooling, PSU and hardware components in the upper and lower sections.
The Level 20 XT takes our latest case innovations and wraps them in an ultra-modern style that’s utterly unique in the case market today.
Stand out from the crowd with the Level 20.

Model Level 20 XT
P/N CA-1L1-00F1WN-00
Case Type E-ATX Cube Case
Dimension (H x W x D) 515 x 394 x 623 mm
(20.3 x 15.5 x 24.5 inch)
Net Weight 20.4 kg / 44.97 lb
Side Panel 4mm Tempered Glass x 4(Left & Right & Front & Top)
Color Exterior & Interior : Black
Material SPCC
Cooling System Rear (exhaust) :
140 x 140 x 25 mm fan (1000rpm, 16dBA)
Drive Bays
-Accessible
-Hidden

6 x 3.5’’ or 2.5’’ (HDD Cage)
1 x 3.5’’, 2 x 2.5’’ (M/B Tray)
Expansion Slots 8
Motherboards 6.7” x 6.7” (Mini ITX), 9.6” x 9.6” (Micro ATX), 12” x 9.6” (ATX), 12” x 13” (Extend ATX)
I/O Port USB 2.0 x2, USB 3.0 x2, HD Audio x 1, Type-C x1
PSU Standard PS2 PSU (optional)
Fan Support Front:
3 x 120mm, 2 x 140mm, 2 x 200mm
Top:
8 x 120mm, 6 x 140mm, 2 x 200mm
Rear:
2 x 120mm or 2 x 140mm
Bottom:
3 x 120mm
Left / Right Side:
4 x 120mm, 3 x 140mm
Radiator Support Front:
1 x 120mm or 1 x 240mm or 1 x 360mm
1 x 140mm or 1 x 280mm
Top:
2 x 120mm or 2 x 240mm or 2 x 360mm or 2 x 480mm
2 x 140mm or 2 x 280mm or 2 x 420mm
Rear:
1 x 120mm or or 1 x 140mm
Left / Right Side:
1 x 120mm or 1 x 240mm or 1 x 360mm or 1 x 480mm
1 x 140mm or 1 x 280mm or 1 x 420mm
Bottom:
1 x 120mm or 1 x 240mm or 1 x 360mm or 1 x 480mm
1 x 140mm or 1 x 280mm or 1 x 420mm
Clearance CPU cooler height limitation:
250mm
VGA length limitation:
400mm(with ODD cage)
590mm(without ODD cage)
PSU length limitation:
220mm (With Bottom Fan)
