General Data | |
Model | Pure Loop 120mm |
Dimensions radiator, incl. fan (H x W x D), (mm) | 157 x 120 x 52 |
Total weight (kg) | 0.78 |
Socket compatibility | Intel 1200 / 2066 / 1150 / 1151 / 1155 / 2011(-3) square ILM; AMD: AM4 / AM3(+) |
Fan model, number | 1x Pure Wings 2 120mm PWM high-speed |
Noise level (dB(A)) @ 25 % / 50% /100% rpm | 18.9 / 23.4 / 36.1 |
Pump speed (rpm) | 5500 |
Pump connector | 3-pin |
Tube length (mm) | 400 |
Refill port | ✓ |
Radiator specifications | |
Dimensions (H x W x D), (mm) | 157 x 120 x 27 |
Radiator material / finish | Aluminum / Black spray painted |
Base material / finish | Copper / Nickel plated |
Fan specifications | |
Fan dimensions (mm) | 120 x 120 x 25 |
Speed @ 100% PWM (rpm) | 2000 |
Bearing technology | Rifle |
Motor technology | 4-pole fan motor |
Rated Voltage (V) | 12 |
Input current (A) | 0.30 |
Input power (W) | 3.6 |
Connector | 4-pin PWM |
Cable length (mm) | 420 |
Lifespan (h / 25°C) | 80,000 |
Accessories | |
Thermal grease | Included |
Mounting set | Intel & AMD |
User manual languages | CN, DE, EN, ES, FR, JP, PL, RU, TW |
Y-cable for fans | - |
Y-SATA Power adaptor for pump & light | ✓ |
Bottle of coolant (ml) | ✓ / 100 |
Service | |
Warranty (Years) | 3 |
International hotline / free of charge | ✓ / DE, FR |
Logistics data, RRP | |
Article number | BW005 |
EAN code | 4260052187883 |
Dimensions, package (L x W x H), (mm) | 321 x 140 x 240 |
Gross weight, package (kg) | 1.66 |
Pieces per packaging unit | 8 |
Dimensions, shipping box (L x W x H), (mm) | 658 x 296 x 508 |
Gross weight, shipping box (kg) | 14.7 |
