EXCEPTIONALLY QUIET, SUPERIOR RELIABILITY, GREAT VALUE
Pure Power 11 600W offers peerless dependability and best-in-class features. Whether you’re assembling a very quiet system, building a multi-GPU gaming system, or upgrading an existing PC, your build will benefit from this PSU that simply has the best combination of features at a very popular price.
General data | |
---|---|
Model | PURE POWER 11 | 600W |
Continuous power (W) | 600 |
Peak power (W) | 650 |
Form factor ATX 12V | Version 2.4 |
Form factor EPS 12V | Version 2.92 |
Modular cable management | - |
Topology | Active Clamp + SR + DC/DC |
Wire-free design (DC-side) | - |
Voltage (Vac) | 100 - 240 |
Frequency (Hz) | 50 - 60 |
Input current (A) | 8 / 5 |
PFC | active |
Power factor at 100% load | >0.99 |
Compliant to Intel C6/C7 | ✓ |
Power consumption in standby (W) | 0.13 |
Average life time (h / 25°C) | 100000 |
Operating temperature up to (°C) | 40 |
Output | |
12V rails (multi-rail operation) | 2 |
12V single rail operation | - |
Overclocking key | - |
+3.3V (A) | 25 |
+5V (A) | 18 |
+12V1 (A) | 32 |
+12V2 (A) | 28 |
+12V3 (A) | - |
+12V4 (A) | - |
+12V5 (A) | - |
+12V6 (A) | - |
-12V (A) | 0.3 |
+5Vsb (A) | 3 |
Max. combined power 12V (W) | 576 |
Max. combined power 3.3V + 5V (W) | 140 |
Hold-up time (ms @ 100%) | 23 |
Fan / Cooling technology | |
Fan type | Silence-optimized be quiet! fan |
+SilentWings | - |
Motor technology | 4-pole fan motor |
Bearing technology | Rifle |
Fan size (mm) | 120 |
Max. fan speed (rpm), temperature-dependent | 1,260 |
Temperature control for case fans | - |
dB(A) at 20% load | 9.1 |
dB(A) at 50% load | 9.6 |
dB(A) at 100% load | 22.9 |
Protection | |
OCP (over current protection) | ✓ |
OVP (over voltage protection) | ✓ |
UVP (under voltage protection) | ✓ |
SCP (short circuit protection) | ✓ |
OTP (over temperature protection) | ✓ |
OPP (over power protection) | ✓ |
Safety certification | |
CE | ✓ |
CB | ✓ |
TÜV | ✓ |
Nemko (N) | - |
Semko (S) | - |
Fimko (FI) | - |
Demko (D) | - |
FCC | ✓ |
cRUus | - |
cTUVus | ✓ |
RCM (Australia) | ✓ |
BSMI | ✓ |
CU (Russia) | ✓ |
CCC | ✓ |
Eco / Efficiency | |
80PLUS certification | Gold |
Efficiency (%) at 230V, 20% load | 87.9 |
Efficiency (%) at 230V, 50% load | 91.2 |
Efficiency (%) at 230V, 100% load | 89.9 |
Environmental directives | |
ENERGY STAR | 6.1 |
ErP | ✓ |
WEEE | ✓ |
RoHS | ✓ |
Cable management / Connectors | |
Multi-GPU ready | ✓ |
Modular cable management | - |
Fully modular | - |
Sleeved cables | ✓ |
Flat cables | - |
Cable length to mainboard (cm) | 55 |
Cable length to first connector (cm) | 50 |
Maximum cable length (cm) | 95 |
All-in-one cable (SATA/PATA/FDD) | ✓ |
No. of cables | 7 |
ATX-Motherboard (20+4-pin) | 1 |
P8 (CPU) | - |
P4+4 (CPU) | 1 |
P4 (CPU) | - |
PCI-E 6-pin (GPU) | - |
PCI-E 6+2-pin (GPU) | 4 |
PATA 4-pin | 3 |
SATA 15-pin (HDD, Drives) | 6 |
FDD (Floppy) | 1 |
External fan connectors | - |
Casing | |
Dimensions without cable (L x W x D), (mm) | 150 x 150 x 86 |
Weight (kg) | 2.07 |
Color | Black |
Accessories | |
Thumb screws | - |
Screws | ✓ |
Cable ties | ✓ |
Velcro cable ties | - |
Box/Bag for PSU/Cables | - |
User manual languages | EN, DE, FR, PL, ES, RU |
OCK slot bracket with switch / OCK jumper | - |
SFX-to-ATX adapter bracket | - |
Service | |
Warranty (Years) | 5 |
Express replacement service in first year | - |
International hotline / free of charge | ✓ / DE, FR |
