RM42200-1, 2x 3.5" Hotswap 3x 3.5" Internal and 3x 5.25" Drive Bays, No PSU, ATX, Black, 4U Chassis
Quantity:
- SKU: 824443
- Manufacturer: CHENBRO
- MPN: RM42200-1
- Availability: USUALLY SHIPS WITHIN 3-5 DAYS
Starting At
$378.06
4U Feature-Advanced Industrial Server Chassis
RM42200 chassis is meant to meet the requirements of Telecom, Military and Appliance Applications. , designed for both rack and pedestal needs in 20.5” depth and support full length card, 5.25" storage kit.
Features and Benefits:
- Robust design for rugged environment
- Utilized 3.5”& 5.25”bays with Chenbro storage kits
- Rotatable cage for ODD or storage kits
- 2 x 3.5" baysfor FDD or 3.5/2.5" HDD with storage kit
- Elegant keylock & outlook
- Adjustable card retainer for low profile or full height PCI card
- Easy-swap front 120 mm fan with filter
Specifications:
| Order Code | RM42200-1 |
| Description | 4U UP Short, 3 x Fixed HDDs, Ideal For Industrial |
| M/B Form Factor | CEB (12"x10.5") |
| Processor | Intel / AMD UP Quad
Intel / AMD DP Quad |
| Support Backplane | N/A |
| Security | Intrusion Switch |
| Chassis Dimension | D x W x H (mm): 522 x 430 x 176 (mm)
D x W x H (inch): 20.5" x 16.9" x 6.9" |
| Power Supply | PS2, ATX or Redundant |
| Drive Bay | External 5.25": 3
External 3.5": 2 Internal 3.5": 3 |
| Generality | Metal Material: SGCC
Metal Thickness: 1.2mm Metal Material: Type ABS-HB |
| Expansion Slots | FF: 7 |
| System Cooling | Front: 1 x 12025 mm |
| Rear Window | Standard |
| Front Panel | Front Control: Power On/Off, System Reset
Indicator: Power Status, HDD Activity (x1), LAN Activity (x1) Ports USB2.0 (x2) |
| Shipping Information | Net Weight (Chassis Only): 13.4 Kg
Gross Weight (w/Packing): 16.05 Kg Cubit Feet: 4.51 Container Information: 20': 195 (Single Packing) 40': 399 (Single Packing) 40'H: 460 (Single Packing) |
