Radeon™ RX 6650 XT SPEEDSTER QICK 308 ULTRA Gaming, 2153 - 2689MHz, 8GB GDDR6, Graphics Card

‍Manufacturer: XFX
Model Number : RX-665X8LUDY
Product Name: AMD Radeon™ RX 6650 XT
Product Description: XFX SPEEDSTER QICK 308 RADEON RX 6650 XT ULTRA Gaming Graphics Card with 8GB GDDR6 HDMI 3xDP, AMD RDNA™ 2
Short Description :  XFX SPEEDSTER QICK 308 RADEON RX 6650 XT ULTRA Gaming Graphics Card
Launch Date: May 2022
UPC Number: 840191500404

‍Bus Type: PCI-E 4.0 @ 8x

‍
Clock Speeds:
Base clock Up to:  2153 MHz
Game Clock Up To:  2486 MHz*
Boost clock Up to:  2689 MHz**

Stream Processors: 2048
Compute Units:  32
Memory Bus:  128 bit
Memory Clock:  17.5 Gbps
Memory Size:  8 GB
Memory Type:  GDDR6
Card Profile: 2.5 Slot
Thermal Solution:  Triple Fan

*"Game Clock" is the expected GPU clock when running in typical gaming applications, set to typical TGP (Total Graphics Power). Actual individual game clock results may vary.

**"Boost Clock" is the maximum frequency achievable on the GPU running a bursty workload. Boost clock achievability, frequency, and sustainability will vary based on several factors, including but not limited to: thermal conditions and variation in applications and workloads.

‍

‍DisplayPort: 1.4 with DSC
HDMI™:  2.1 VRR and FRL
Output :  Display Port 3
Output:  HDMI 1

‍

‍External Power: 1x PCI-E 8 pin connections
Minimum Power Supply Requirement:  500 watt
XFX Recommended Power Supply:  XFX 600W PSU

‍

RoHS

Installation Guide: 1

‍Card Dimension (cm): 27.4 x 11.4 x 5
Card Dimension (inch):  10.79 x 4.49 x 1.97
Master Carton Dimensions (cm):  47 x 41 x 37.5
Master Carton Dimensions (inch):  18.5 x 16.14 x 14.76
Master Carton Weight (Kg):  15
Master Carton Weight (lb):  33.07
Package Dimensions (cm):  36x 19.3 x 9.3
Package Dimensions (inch):  14.17 x 7.6 x 3.66
Package Weight (Kg):  1.34
Package Weight (lb):  2.95
Units/Carton:  10

AMD RDNA™ 2 Architecture
DirectX® 12 Ultimate
Hardware Raytracing
FidelityFX™
Radeon™ Anti-Lag
Microsoft® Windows® 10 Support
Microsoft® DirectX™ 12 Support
7nm Technology
GDDR6 Memory
PCI® Express 4.0 Support
AMD FreeSync™ Technology*
DisplayPort™ 1.4 with DSC
HDMI™ 2.1 VRR
Video Streaming up to 8K
AMD FidelityFX*
Radeon™ Image Sharpening*
Radeon™ Anti-Lag*
AMD Software: Adrenalin Edition
Game Driver Optimizations
OpenGL Support
OpenCL Support

‍

‍

* Not compatible with Windows 7. For more information on Radeon™ technologies, visit: AMD.com/gamingdetails

‍

Advanced 7nm GPU
PCI Express 4.0 Support
Radeon™ Image Sharpening
FidelityFX™
Radeon™ Anti-Lag
Microsoft® Windows® 10 Support
Microsoft® DirectX™ 12 Support
7nm Technology
AMD Virtual Super Resolution (VSR)
AMD Software Media Recording andStreaming
AMD FreeSync™ 2 HDR
AMD Frame Rate Target Control (FRTC)
AMD Eyefinity™ multi-display technology
AMD Software Performance Tuning
Displayport 1.4 w/ DSC
Dolby TrueHD and DTS-HD Master Audio Support
OpenGL Support
OpenCL Support
