Mechanical specifications | |
Dimensions (L x W x H), (mm) | 120 x 120 x 25 |
Bearing technology | Rifle |
Motor technology | 4-pole fan motor |
Weight incl. fixed cables (kg) | 0.131 |
Push pin fixing | ✓ |
Screw fixing | - |
Cables / Connectors | |
Connector | 3-Pin |
Cable length (mm) | 500 |
Cable sleeve | - |
Performance / Noise | |
Air flow @ 100% PWM / 12V (cfm / m3/h) | 38.5 / 65 |
Air pressure @ 100% PWM / 12V (mm H2O) | 0.82 |
Noise level @ 100% PWM / 12V (dB(A)) | 15.7 |
Lifespan (h / 25°C) | 80000 |
Electrical specifications | |
Rated voltage DC (V) | 12 |
Operating voltage DC (V) | 6 - 12 |
Current consumption (A) | 0.12 |
Safety current (A) | 0.12 |
Input power (W) | 1.44 |
Accessories | |
3-pin to 4-pin 12V-connector | - |
12V to 7V adapter | - |
12V to 5V adapter | - |
Screws | - |
Push pins | 4 |
Silica gel washer | 4 |
Others | - |
Safety certification | |
Approvals | CE, TÜV, UL |
Service | |
Warranty (Years) | 3 |
International hotline / free of charge | ✓ / DE, FR |
Logistics data, RRP | |
Article number | BL088 |
EAN code | 4260052187326 |
Dimensions, package (L x W x H), (mm) | 155 x 120 x 28 |
Gross weight, package (kg) | 0.152 |
Pieces per packaging unit | 60 |
Dimensions, shipping box (L x W x H), (mm) | 410 x 320 x 290 |
Gross weight, shipping box (kg) | 10.46 |
