Virtually inaudible operation at max. 15.5dB(A)
6-pole fan motor for less power consumption and vibration
Fluid-dynamic bearing enables super-long life span of 300,000h
Fan frame with funnel-shaped air inlets for extremely high air pressure
Seven fan blades offer an optimized airflow
PWM controlled fan speed by the motherboard
German product conception, design and quality control
Three years manufacturer’s warranty
Specifications
- Mfr Part Number: BL067
- Features:
- Virtually inaudible operation at max. 15.5dB(A)
- 6-pole fan motor with three phases giving very low power consumption and less vibration
- Advanced fluid-dynamic bearing (FDB) enables a super long fan life of up to 300,000 hours
- Seven fan blades with optimized surface structures ensure excellent airflow
- The rubberized fan frame is equipped with funnel-shaped air inlets producing extremely high air pressure
- Removable anti-vibration mountings minimize the transmission of vibrations to the PC case and its components
- Advanced high quality IC motor controller reduces electrical noise
- Pulse width modulation (PWM) allows compatible 4-pin controllers (including those built into many motherboards) to intelligently vary the speed of the fan
- With PWM your system can ramp up the cooling when it's needed, or operate in maximum quiet mode when it's not
- Fan Speed: 1000 RPM
- Air Flow: 59.5 CFM / 101.09 m3/h
- Air Pressure: 1.08 mmH2O
- Noise Level: 15.5 dBA
- Voltage: Rated - 12 VDC, Operating - 4 ~ 13.2 VDC
- Current: 0.06 A (consumption), 0.3 A (safety)
- Input Power: 0.72 W
- Bearing: Fluid Dynamic Bearings (FDB)
- Motor: 6-pole Fan Motor
- Connector: 4 Pin PWM
- Cable Length: 500 mm
- Life: 300,000 hours
- Approvals: CE, RoHS, WEEE, RU, Tuv
- Dimensions: 140.0 x 140.0 x 25.0 mm
- Weight: 0.167 kg
