General | |
Energy Saving | GreenPower UPS™ High Efficiency |
Energy Star Certified | Yes |
UPS Topology | Standby |
Battery | |
Battery Quantity | 1 |
Battery Size | 12V / 7.2AH |
Battery Type | Sealed Lead-Acid |
Hot Swappable | No |
Replacement Battery Cartridge | TBD |
Runtime at Full Load | 2 min |
Runtime at Half Load | 7.5 min |
Typical Recharge Time | 8 hours |
User Replaceable | Field replacement |
Dimensions | |
Physical Dimensions – (WxHxD) (cm) | 30.99 x 7.87 x 17.78 (cm) |
Physical Dimensions – (WxHxD) (in) | 12.2 x 3.1 x 7 (in) |
Physical Dimensions – (WxHxD) (mm) | 310 x 79 x 178 (mm) |
Weight (kg) | 3.49 |
Weight (lb) | 7.7 |
Dimensions – Shipping | |
Shipping – Weight (kg) | 4.26 |
Shipping – Weight (lb) | 9.4 |
Shipping Dimensions – (WxHxD) (cm) | 38.1 x 10.95 x 24.13 (cm) |
Shipping Dimensions – (WxHxD) (in) | 15 x 4.31 x 9.5 (in) |
Shipping Dimensions – (WxHxD) (mm) | 381.0 x 109.47 x 241.3 (mm) |
Input | |
Circuit Breaker | 15 A |
Cord Length (ft) | 5 |
Frequency Range | 47 – 63 Hz |
Input Voltage Range | 96Vac – 140Vac |
Plug Type | NEMA 5-15P |
Output | |
On Battery Frequency | 50Hz/60Hz ± 1% |
On Battery Voltage | 120Vac ± 5% |
On Battery Waveform | Simulated sine wave |
Outlet Type | NEMA 5-15R |
Outlets – Battery & Surge Protected | 6 |
Outlets – Surge-Only Protected | 6 |
Outlets – Total | 12 |
Outlets – Widely Spaced | 4 |
Overload Protection | Internal circuitry limiting / circuit breaker |
Rated Power Factor | 0.56 |
Transfer Time | Typical 8ms |
USB Charge Ports | 2 (2.1 Amps Shared) |
VA | 900 |
Watts | 500 |
Surge Protection & Filtering | |
EMI/RFI Filtration | Yes |
Surge Suppression | 890 |
Management & Communications | |
Audible Alarms | On battery, low battery, overload, fault |
HID Compliant USB Port | Yes |
LED Indicators | Power On |
Multifunction LCD Panel | No |
Serial Port | No |
Software | PowerPanel® Personal Edition |
Physical | |
Color | Black |
Dimensions – W×H×D (in) | 12.2 × 3.1 × 7 |
Form Factor | Compact |
Keyhole Mounting Slots | Yes |
Weight (lbs) | 7.7 |
Environmental | |
Maximum Operating Elevation | 10,000 ft (3,000 m) |
Maximum Storage Elevation | 50,000 ft (15,000 m) |
Operating Relative Humidity | 0 – 95% (non-condensing) |
Operating Temperature | 32 °F to 104°F (0°C to 40°C) |
Storage Temperature | 5°F to 113°F (-15°C to 45°C) |
Certifications | |
Environmental | RoHS Compliant |
Safety | UL1778, cUL, FCC DOC Class B, CEC |
Warranty | |
Connected Equipment Guarantee | Lifetime |
Product Warranty | 3 Years Limited |
