Xeon® E3-1230 v6 4-Core 3.5 - 3.9GHz Turbo, LGA 1151, 8 GT/s DMI3, 72W, OEM Processor

Quantity:
  • SKU: 11183756
  • Manufacturer: INTEL
  • MPN: CM8067702870650
  • Availability: LOW STOCK
Starting At
$350.75
As low as $11.32/ Month*
Quantity:
Essentials
  • Product Collection: Intel® Xeon® Processor E3 v6 Family
  • Code Name: Products formerly Kaby Lake
  • Vertical Segment: Server
  • Processor Number: E3-1230V6
  • Status: Launched
  • Launch Date: Q1'17
  • Lithography: 14 nm
Performance
  • # of Cores: 4
  • # of Threads: 8
  • Processor Base Frequency: 3.50 GHz
  • Max Turbo Frequency: 3.90 GHz
  • Cache: 8 MB
  • Bus Speed: 8 GT/s DMI3
  • TDP: 72 W
  • VID Voltage Range: 0.55V-1.52V
Supplemental Information
  • Embedded Options Available: No
  • Conflict Free: Yes
Memory Specifications
  • Max Memory Size (dependent on memory type): 64 GB
  • Memory Types: DDR4-2400, DDR3L-1866
  • Max # of Memory Channels: 2
  • Max Memory Bandwidth: 37.5 GB/s
  • ECC Memory Supported: Yes
Graphics Specifications
  • Processor Graphics: None
  • Graphics Output: N/A
  • 4K Support: No
  • Max Resolution (HDMI 1.4): N/A
  • Max Resolution (DP): N/A
  • Max Resolution (eDP - Integrated Flat Panel): N/A
  • Max Resolution (VGA): N/A
  • DirectX* Support: N/A
  • OpenGL* Support: N/A
  • Intel® Quick Sync Video: No
  • Intel® InTru™ 3D Technology: No
  • Intel® Clear Video HD Technology: No
  • Intel® Clear Video Technology: No
  • # of Displays Supported: 0
Expansion Options
  • Scalability: 1S Only
  • PCI Express Revision: 3.0
  • PCI Express Configurations: 1x16, 2x8, 1x8+2x4
  • Max # of PCI Express Lanes: 16
Package Specifications
  • Sockets Supported: FCLGA1151
  • Max CPU Configuration: 1
  • Package Size: 37.5mm x 37.5mm
  • Low Halogen Options Available: See MDDS
Advanced Technologies
  • Intel® Turbo Boost Technology: 2.0
  • Intel® vPro Technology: Yes
  • Intel® Hyper-Threading Technology: Yes
  • Intel® Virtualization Technology (VT-x) Yes
  • Intel® Virtualization Technology for Directed I/O (VT-d): Yes
  • Intel® VT-x with Extended Page Tables (EPT): Yes
  • Intel® TSX-NI: Yes
  • Intel® 64:  Yes
  • Instruction Set: 64-bit
  • Instruction Set Extensions: SSE4.1/4.2, AVX 2.0
  • Idle States: Yes
  • Enhanced Intel SpeedStep® Technology: Yes
  • Thermal Monitoring Technologies: Yes
Intel® Data Protection Technology
  • Intel® AES New Instructions: Yes
  • Secure Key: Yes
  • Intel® Software Guard Extensions (Intel® SGX): Yes
  • Intel® Memory Protection Extensions (Intel® MPX): Yes
Intel® Platform Protection Technology
  • OS Guard: Yes
  • Trusted Execution Technology:  Yes
  • Execute Disable Bit: Yes
  • Intel® Device Protection Technology with Boot Guard: Yes
