Essentials | |
Product Collection | Intel® Xeon® W Processor |
Code Name | Products formerly Rocket Lake |
Vertical Segment | Workstation |
Processor Number | W-1350P |
Status | Launched |
Launch Date | Q2'21 |
Lithography | 14 nm |
Included Items | This product is available in tray and box. For boxed product, a thermal solution is included. |
Use Conditions | Workstation |
CPU Specifications | |
# of Cores | 6 |
# of Threads | 12 |
Processor Base Frequency | 4.00 GHz |
Max Turbo Frequency | 5.10 GHz |
Cache | 12 MB Intel® Smart Cache |
Bus Speed | 8 GT/s |
Intel® Turbo Boost Technology 2.0 Frequency | 5.10 GHz |
TDP | 125 W |
Configurable TDP-down Frequency | 3.00 GHz |
Configurable TDP-down | 95 W |
Supplemental Information | |
Embedded Options Available | No |
Datasheet | View now |
Memory Specifications | |
Max Memory Size (dependent on memory type) | 128 GB |
Memory Types | DDR4-3200 |
Max # of Memory Channels | 2 |
Max Memory Bandwidth | 50 GB/s |
ECC Memory Supported | Yes |
Processor Graphics | |
Processor Graphics | Intel® UHD Graphics P750 |
Graphics Base Frequency | 350 MHz |
Graphics Max Dynamic Frequency | 1.30 GHz |
Graphics Video Max Memory | 64 GB |
Execution Units | 32 |
4K Support | Yes, at 60Hz |
Max Resolution (HDMI) | 4096x2160@60Hz |
Max Resolution (DP) | 5120 x 3200 @60Hz |
Max Resolution (eDP - Integrated Flat Panel) | 5120 x 3200 @60Hz |
DirectX* Support | 12. |
OpenGL* Support | 04. |
Intel® Quick Sync Video | Yes |
Intel® InTru™ 3D Technology | Yes |
Intel® Clear Video HD Technology | Yes |
Intel® Clear Video Technology | Yes |
# of Displays Supported | 3 |
Device ID | 0x4C90 |
OpenCL* Support | 3.0 |
Expansion Options | |
Scalability | 1S Only |
PCI Express Revision | 4.0 |
PCI Express Configurations | Up to 1x16+1x4, 2x8+1x4, 1x8+3x4 |
Max # of PCI Express Lanes | 20 |
Package Specifications | |
Sockets Supported | FCLGA1200 |
Max CPU Configuration | 1 |
Thermal Solution Specification | PCG 2019A |
TJUNCTION | 100°C |
Package Size | 37.5 mm x 37.5 mm |
Advanced Technologies | |
Intel® Deep Learning Boost (Intel® DL Boost) | Yes |
Intel® Optane™ Memory Supported | Yes |
Intel® Thermal Velocity Boost | No |
Intel® Turbo Boost Max Technology 3.0 | No |
Intel® Turbo Boost Technology | 2.0 |
Intel vPro® Platform Eligibility | Yes |
Intel® Hyper-Threading Technology | Yes |
Intel® Virtualization Technology (VT-x) | Yes |
Intel® Virtualization Technology for Directed I/O (VT-d) | Yes |
Intel® VT-x with Extended Page Tables (EPT) | Yes |
Intel® 64 | Yes |
Instruction Set | 64-bit |
Instruction Set Extensions | Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2, Intel® AVX-512 |
Idle States | Yes |
Enhanced Intel SpeedStep® Technology | Yes |
Thermal Monitoring Technologies | Yes |
Intel® Identity Protection Technology | Yes |
Intel® Gaussian and Neural Accelerator 2.0 | Yes |
Security & Reliability | |
Intel® AES New Instructions | Yes |
Secure Key | Yes |
Intel® Software Guard Extensions (Intel® SGX) | No |
Intel® OS Guard | Yes |
Intel® Trusted Execution Technology | Yes |
Execute Disable Bit | Yes |
Intel® Boot Guard | Yes |
