General |
Brand |
Mushkin Enhanced |
Series |
GAMMA |
Model |
MKNSSDGA8TB-D8 |
Type |
M.2 (2280) Internal Solid State Drive (SSD) |
Used For |
Consumer |
UPC |
846651030641 |
Physical |
Form Factor |
M.2 (2280) |
Capacity |
8TB |
Memory Components |
3D NAND |
Interface |
PCIe Gen4 x4 NVMe 1.4 |
Controller |
Phison E18 |
Height |
3.8mm |
Width |
80.0mm |
Depth |
22.0mm |
Weight |
7g |
Performance |
Max Sequential Read |
Up to 7000 MB/s |
Max Sequential Write |
Up to 5900 MB/s |
4KB Random Read |
Up to 700,000 IOPS |
4KB Random Write |
Up to 1,000,000 IOPS |
Seek Time |
<0.1ms |
Total Bytes Written (TBW) |
6000TB |
MTBF |
1,600,000 hours |
Features |
Features |
MEDS (Mushkin Enhanced Data-protection Suite) ensures valuable data is protected |
- Built-in LDPC ECC provides the most-powerful data correction level in use today |
- End-to-end data path protection |
- SmartECC |
- Thermal Monitoring |
- Hardware encryption: AES 128/256 bit SHA160/256/512, RSA 2048 |
- Enhanced Power Management |
- RoHS, FCC, CE |
Environmental |
Operating Temperature |
0°C-70°C |
Storage Temperature |
-40°C-85°C |
Max Shock Resistance |
1500G |
Power Supply |
3.3V DC |
