Form factor |
M.2 2280 |
Interface |
NVMe™ PCIe Gen 3.0 x 4 Lanes |
Capacities |
500GB |
Controller |
SMI 2262EN |
NAND |
96-layer 3D TLC |
Encrypted |
AES 256-bit Encryption |
Sequential Read/Write |
500GB – up to 3,000/2,000MB/s |
Random 4K Read/Write |
500GB – up to 350,000/250,000 IOPS |
Total Bytes Written (TBW) |
500GB – 300TBW |
Power Consumption |
.003W Idle / .2W Avg / 2.1W (MAX) Read / 7W (MAX) Write |
Storage Temperature |
-40°C~85°C |
Operating temperature |
0°C~70°C |
Dimensions |
80mm x 22mm x 3.5mm |
Weight |
500GB – 10g |
Vibration Operating |
2.17G Peak (7-800Hz) |
Vibration Non-operating |
20G Peak (20-1000Hz) |
MTBF |
2,000,000 |
Warranty/support |
Limited 5-year warranty with free technical support |
