1.6TB CM6-V 15mm, 6900 / 2800 MB/s, 3D TLC NAND, PCIe NVMe 4.0 x4, SED, TCG Enterprise/Opal SSC, U.3 2.5" SSD
Quantity:
- SKU: 13784390
- Manufacturer: Kioxia
- MPN: KCM6DVUL1T60
- Availability: TEMPORARILY OUT OF STOCK
Starting At
$337.07
1.6TB CM6-V 15mm, 6900 / 2800 MB/s, 3D TLC NAND, PCIe NVMe 4.0 x4, SED, TCG Enterprise/Opal SSC, U.3 2.5" SSD
KIOXIA 1.6TB KCM6DVUL1T60. The CM6-V series is a mixed-use SSD that is optimized to support a broad range of enterprise applications and associated workloads, including high performance computing, online transaction processing, IoT and edge computing, media streaming. Built on PCIe® 4.0 and NVMe™1.4 technology, the CM6 Series SSDs deliver excellent performance up to 1.4M IOPS (random read) and 350 KIOPS (random write), with maximum power consumption of 25 W.
- PCIe® 4.0, NVMe™ 1.4 specification compliant
- Form factor: 2.5-inch, 15mm Z-height
- Proprietary KIOXIA architecture: controller, firmware and BiCS FLASH™ 96-layer 3D TLC memory
- SFF-TA-1001 conformant (U.3), works with Tri-mode controllers and backplanes
- Dual-port design for high availability applications
- 6th generation, two-die failure recovery and double parity protection
- High performance with lower power consumption
- Power loss protection (PLP) and end-to-end data protection
- Suited for 24x7 enterprise workloads
- Data security options: SIE, SED, FIPS 140-2[1, 2, 3, 4, 5]
- Six power mode settings
| SED Model Number | KCM6DVUL1T60 |
| Capacity | 1,600 GB |
| Physical | |
| Interface Specification | PCIe® 4.0, NVMe™ 1.4 |
| Interface Speed | 64 GT/s (Gen4 1x4, 2x2) |
| Memory Type | BiCS FLASH™ TLC |
| Performance in single port (1x4) mode(Up to) | |
| Sustained 128 KiB Sequential Read | 6,900 MB/s |
| Sustained 128 KiB Sequential Write | 2,800 MB/s |
| Sustained 4 KiB Random Read | 1,300,000 IOPS |
| Sustained 4 KiB Random Write | 215,000 IOPS |
| Power Requirements | |
| Supply Voltage | 12 V ± 10%, 3.3 Vaux ± 15% |
| Power Consumption (Active) | 14 W Typ. |
| Power Consumption (Ready) | 5.0 W Typ. |
| Reliability | |
| MTTF | 2,500,000 hours |
| Warranty | 5 years |
| DWPD | 3 |
| Mechanical | |
| Height | 15.0 mm + 0, - 0.5 mm |
| Width | 69.85 ± 0.25 mm |
| Length | 100.45 mm Max |
| Weight | 130 g Max. |
| Environmental | |
| Temperature (Operating) | 0 °C to 70 °C |
| Humidity (Operating) | 5 % to 95 % R.H. |
| Vibration (Operating) | 21.27 m/s2 { 2.17 Grms } ( 5 to 800 Hz ) |
| Shock (Operating) | 9,800 m/s2 { 1,000 G } ( 0.5 ms duration ) |
