Capacity' | 14TB |
Model Number (Retail packaging) | HDWG51EXZSTB |
Model Number (Bulk) | HDWG51EUZSVB |
Interface | SATA 6.0 Gbit/s |
Form Factor" | 3.5-inch |
Advanced Format (AF) | Yes |
RoHS Compatible" | Yes |
Sector Size | 512e |
Drive Bays Supported' | Up to 24 |
Ramp Loading Technology | Yes |
Rotational Vibration (RV) Sensors | Yes |
Native Command Queuing (NCQ) | Yes |
Shock Sensor | Yes |
Toshiba Cache Technology | Yes |
Recording Technology | CMR |
Rotational Speed [RPM] | 7,200 |
Max Data Transfer Speed4 [MB/s Typ.] (Sustained) | 281 |
Cache Size [MB] | 512 |
24 x 7 Operation" | Yes |
Maximum Workload Rate [TB/Year)'·" | 300 |
MTTF/MTBF [Hours]" | 1,200,000 |
Unrecoverable Error Rate | 1 per 10" |
Load/ Unload Cycles | 600,000 |
Limited Warranty' [Years] | 5 |
Supply Voltage |
5 VDC +10 / -7 % 12VDC±10% |
Power Consumption (Operating) [WJ | 7.38 |
Power Consumption (Active Idle) [W) | 3.77 |
Temperature (Operating) [ ' CJ | 0 to 65 (surface) |
Temperature (Non-operating) [ ' CJ | -40 to 70 |
Vibration (Operating) {m/ s'] |
7.35 (0.75GI {5 to 300Hz) 2.45 (0.25G} (300 to SOOHz) |
Vibration (Non-Operating) (m/ s' ] | 29.4 (3.0G) (5 to S00Hz) |
Shock (Operating) [m/ s'] | 686 {70G} (2 ms duration) |
Shock (Non-Operating) [m/s'] | 2,450 {250G) (2 ms duration) |
Acoustics Idle Mode [dB] | 34 |
Height (mm Max.] | 26.1 |
Length {mm Max.] | 147.0 |
Width [mm Max.] | 101.85 |
Weight [g Max.] | 705 |
Bottom Holes Type• | TYPEl |
