| Essentials |
| Capacity |
180 GB |
| Status |
Launched |
| Launch Date |
Q1'16 |
| Lithography Type |
16nm |
| Performance |
| Sequential Read (up to) |
560 MB/s |
| Sequential Write (up to) |
475 MB/s |
| Random Read (8GB Span) (up to) |
71000 IOPS |
| Random Write (8GB Span) (up to) |
85000 IOPS |
| Latency - Read |
50 µs |
| Latency - Write |
50 µs |
| Power - Active |
80 mW Typical |
| Power - Idle |
40 mW Typical |
| Reliability |
| Vibration - Operating |
2.17 GRMS (5-700Hz) |
| Vibration - Non-Operating |
3.13 GRMS (5-800Hz) |
| Shock (Operating and Non-Operating) |
1000 G/0.5 ms |
| Operating Temperature Range |
0°C to 70°C |
| Mean Time Between Failures (MTBF) |
1.6 Million Hours |
| Uncorrectable Bit Error Rate (UBER) |
<1 sector per 10^16 bits read |
| Warranty Period |
5 yrs |
| Package Specifications |
| Form Factor |
M.2 22 x 80mm |
| Interface |
SATA 3.0 6Gb/S |
| Advanced Technologies |
| Enhanced Power Loss Data Protection |
No |
| Hardware Encryption |
AES 256 bit |
| High Endurance Technology (HET) |
No |
| Temperature Monitoring and Logging |
No |
| End-to-End Data Protection |
No |
| Intel® Smart Response Technology |
Yes |
| Intel® Rapid Start Technology |
Yes |
