General |
Brand |
Mushkin Enhanced |
Series |
Vortex LX |
Model |
MKNSSDVL1TB-D4 |
Type |
M.2 (2242) Internal Solid State Drive (SSD) |
Used For |
Consumer |
Physical |
Form Factor |
M.2 (2242) |
Capacity |
1TB |
Interface |
PCIe Gen4 x4 NVMe 1.4 |
Controller |
InnoGrit IG5220 |
Height |
3.8mm |
Width |
42.0mm |
Depth |
22.0mm |
Weight |
7g |
Performance |
Max Sequential Read |
Up to 5200MB/s |
Max Sequential Write |
Up to 4370MB/s |
MTBF |
1,500,000 hours |
TBW |
500 |
Features |
Features |
MEDS (Mushkin Enhanced Data-protection Suite) ensures valuable data is protected |
- Built-in LDPC ECC provides the most-powerful data correction level in use today |
- End-to-end data path protection |
- Global wear-leveling evens program/erase counts across data blocks to extend lifespan |
Host Memory Buffer (HMB) uses system DRAM to boost performance |
SLC caching accelerates burst performance |
L1.2 power mode support for ultra-low power consumption |
NVMe Security Erase support |
NVMe Deallocate function support (NVMe equivalent of TRIM command) |
High-reliability 3D NAND flash |
S.M.A.R.T. support |
User-upgradeable firmware |
Temperature sensor |
RoHS, FCC, CE |
Power Consumption (Idle): 80mW |
Power Consumption (Active): Up to 5W |
Max sequential speeds and IOPS measured using CrystalDiskMark 8.0.1 x64. |
Environmental |
Operating Temperature |
0°C-70°C |
Storage Temperature |
-40°C-85°C |
Max Shock Resistance |
1500G |
Power Supply |
3.3V DC |
