| DISPLAY |
| Diagonal |
23.8" |
| Resolution |
1920 x 1080 |
| Panel Type |
IPS |
| Backlight Type |
Direct |
| Aspect Ratio |
16:9 |
| Pixel Pitch |
0.2745 x 0.2746 mm |
| Brightness (Typ.) |
250 nits |
| Color Gamut (Typ.) |
NTSC 72% (CIE1931) |
| Color Depth (Number of Colors) |
16.7M |
| Color Bit |
8bit (6bit + FRC) |
| Contrast Ratio (Typ.) |
1000:1 |
| Response Time (GTG) |
5ms (GtG at Faster) |
| Viewing Angle (CR≥10) |
178° |
| Surface Treatment |
Anti-Glare |
| Flicker Safe |
Yes |
| Picture Mode |
Custom, Reader, Color Weakness, Photo, Cinema, Game |
| Reader Mode |
Yes |
| Color Weakness |
Yes |
| Super Resolution+ |
Yes |
| AMD FreeSync™ |
Yes |
| Black Stabilizer |
Yes |
| Dynamic Action Sync |
Yes |
| Crosshair |
Yes |
| Smart Energy Saving |
Yes |
| SOFTWARE APPLICATIONS |
| OnScreen Control / Switch |
Yes |
| CONNECTIVITY |
| D-Sub |
Yes (1ea) |
| HDMI |
Yes(1ea) |
| HDMI Version |
2.0 |
| HDMI (HDCP Version) |
1.4 |
| DisplayPort |
Yes (1ea) |
| DP Version |
1.2 |
| DP (HDCP Version) |
1.4 |
| SOUND |
| Built-in Speaker |
No |
| POWER |
| Type |
External Power (Adapter) |
| POWER |
| AC Input |
100-240 Vac, 50/60 Hz |
| DC Output |
24W (19V, 1.3A) |
| Power Consumption (Typ.) |
19W |
| POWER |
| Power Consumption (Max.) |
22W |
| POWER |
| Power Consumption (Sleep Mode) |
Less than 0.3 W |
| Power Consumption (DC Off) |
Less than 0.3W |
| MECHANICAL |
| Borderless Design |
3-Side Virtually Borderless Design |
| Color (Front Cabinet) |
Black |
| Color (Middle Cabinet) |
Black |
| Color (Back Cover) |
Black |
| Color (Stand Body) |
Black |
| Color (Stand Base) |
Black |
| Display Position Adjustments |
Tilt/Height/Swivel/Pivot |
| Tilt |
-5 to +35° |
| Swivel |
0 to 355° |
| Height Range |
130 mm |
| Down Height |
71.1 mm |
| Pivot |
Bi-Direction |
| Extend/Retract |
N/A |
| Wall Mountable |
75 x 75 mm |
| Dimensions with Stand (W x H x D) |
21.3 x 19.9 x 9.8 in 539.9 x 506 x 249.5 mm |
| Dimensions without Stand (W x H x D) |
21.3 x 14.8 x 2.2 in 539.9 x 376 x 56.2 mm |
| Shipping Dimensions (W x H x D) |
23.9 x 15.9 x 6.9 in 607 x 404 x 175 mm |
| Weight with Stand |
9.5 lbs / 4.3 kg |
| Weight without Stand |
5.1 lbs / 2.3 kg |
| Shipping Weight |
12.6 lbs / 5.7 kg |
| CERTIFICATIONS & STANDARDS |
| EPA 8.0 |
Yes |
| TUV-TYPE |
Yes |
| UL (cUL) |
Yes |
| FCC-B |
Yes |
| EPEAT (USA) |
Yes |
| ErP |
Yes |
| CE |
Yes |
| ROHS, REACH |
Yes |
| ACCESSORIES AND UPC |
| Adapter (Color) |
Black |
| Power Cord |
Black / 1.5m |
| HDMI Cable |
Black / 1.8m |
| UPC Code |
1 95174 03846 8 |
