| Display |
| Aspect Ratio |
16:9 |
| Brightness (Typ.) |
350 cd/m² |
| Color Bit |
10bit |
| Color Gamut (Typ.) |
sRGB over 99%(Coverage) |
| Contrast Ratio (Typ.) |
1000:1 |
| Panel Type |
IPS |
| Resolution |
3840 x 2160 |
| Response Time (GTG) |
14ms (Off-setting), 5ms (Faster-setting) |
| Size (Inch) |
27 |
| Surface Treatment |
Anti-glare, 3H |
| Viewing Angle (CR≥10) |
178° (Right/Left), 178° (Up/Down) |
| Feature |
| Brightness stabilization |
Yes |
| HW Calibration |
Yes(LG Calibration Studio) |
| DICOM Compliant |
Yes |
| Color Temperature |
6500K / 8500K / 9300K Manual (5000K ~ 10000K) |
| Flicker safe |
Yes |
| PBP |
Yes (2PBP) |
| Reader Mode |
Yes |
| Smart Energy Saving |
Yes |
| Super Resolution+ |
Yes |
| SW Application |
| Dual Controller |
Yes |
| LG Calibration Studio |
Yes |
| Connectivity |
| DisplayPort |
Yes(1ea) |
| HDMI |
Yes(2ea) |
| Composite |
Yes |
| S-Video |
Yes |
| Component |
Yes |
| Headphone out |
Yes |
| USB Downstream Port |
Yes (2ea/ver3.0) |
| USB Upstream Port |
Yes (1ea/ver3.0) |
| Power |
| AC Input |
100-240Vac, 50/60Hz |
| DC Output |
19V, 3.42A |
| Power Consumption (DC Off) |
Less than 0.3W |
| Power Consumption (Max.) |
65W |
| Type |
External Power(Adapter) |
| Mechanical |
| Borderless Design |
3-Side Virtually Borderless Design |
| Display Position Adjustments |
Tilt/Height/Pivot |
| Down Height |
80.4mm |
| Height Range |
110mm |
| OneClick Stand |
Yes |
| Pivot |
Yes(±90°) |
| Tilt |
Yes(-3°~20°) |
| Wall Mount Size |
100x100mm |
| Dimensions/Weight |
| Dimension in Shipping (W x H x D) |
832 x 473 x 168 mm |
| Dimension with Stand (W x H x D) |
615 x 222.6 x 535.2 mm |
| Dimension without Stand (W x H x D) |
615 x 365.1 x 42.7 mm |
| Pallet Stuffing (20ft/40ft/40ft HC) |
360EA/744EA/868EA |
| Weight in Shipping |
10.1kg(22.3lb) |
| Weight with Stand |
6.2kg(13.7lb) |
| Weight without Stand |
4.7kg(10.4lb) |
| Standard |
| IEC (IEC 60601-1 / IEC 60601-1-2) |
Yes |
| EN (EN 60601-1 / EN 60601-1-2) |
Yes |
| IEC (IEC 60950-1 & IEC 62368-1 / CISPR 32, 35) |
Yes |
| EN (EN 62368-1 / EN 55032, 55035) |
Yes |
| cUL (ANSI/AAMI ES 60601-1, CSA CAN/CSA-C22.2 NO. 60601-1) |
Yes |
| CE |
MDR |
| FDA |
Registration (Class I) |
| ISO13485 |
Yes |
| RoHS |
Yes |
| REACH |
Yes |
| WEEE |
Yes |
| MFDS |
Yes |
| Accessory |
| Adapter |
Yes |
| Calibration Report (Paper) |
Yes |
| Display Port |
Yes |
| HDMI |
Yes |
| Power Cord |
Yes |
| USB3.0 Upstream Cable |
Yes |
