Specification | |
Form Factors | M.2 2280 |
Interface | PCIe Gen3 X4 NVMe v1.3 |
Capacity | 2TB |
Security | TCG OPAL 2.01, SSC support |
Performance | |
Sequential Read (128KB MB/s up to) | 3,470 |
Sequential Write (128KB MB/s up to) | 2,800 |
Random Read (4KB, 32QD, IOPS up to) | 450K |
Random Write (4KB, 32QD, IOPS up to) | 390K |
Sustained Sequential Write (128KB MB/s up to) | 1,380 |
Sustained Random Write (4K, IOPS up to) | 3,200 |
Sustained Random 70/30 Read/Write (4K, IOPS up to) | 9,000 |
Endurance (TBW) | 1600 |
Peak Power (10μs) (A) | 2.8 |
Average Active Power (mW) | up to 140 |
Low Power (PS3) (mW) | up to 100 |
Sleep (PS4) (MW) | 2.5 |
Supply Voltage (V / +5%) | 3.3 |
Reliability | |
MTTF | up to 2M hours |
UBER | 10-17 |
Environmental | |
Operating Temperatures | 0°C to 85°C |
Non-operating Temperatures1 | -55°C to 85°C |
Certifications | FCC, UL, TUV, KCC, BSMI, VCCI, C-Tick |
Limited Warranty" | 5 years |
Physical Dimensions | |
Width | 22mm ± 0.15mm |
Length | 80mm ± 0.15mm |
Thickness (max) | 2.38mm |
Weight | 7.5g + 1g |
