Specifications |
Capacity |
2TB |
Standard Model Number |
ST2000NT001 |
Interface |
SATA 6Gb/s |
Features |
Drive Bays Supported |
Unlimited |
Recording Technology |
CMR |
Drive Design (Air or Helium) |
Air |
Workload Rate Limit (WRL) |
550 |
Rotational Vibration (RV) Sensors |
Yes |
Cache (MB) |
256MB |
Reliability/Data Integrity |
Mean Time Between Failures (MTBF, hours) |
2,000,000 hr |
Non-recoverable Read Errors per Bits Read, Max |
1 per 10E15 |
Power-On Hours (per year) |
8,760 |
Sector Size (Bytes per Logical Sector) |
512E |
Rescue Data Recovery Services (years) |
3 |
Limited Warranty (years) |
5 |
Performance |
Spindle Speed (RPM) |
7200RPM |
Interface Access Speed (Gb/s) |
6.0, 3.0, 1.5 |
Max. Sustained Transfer Rate OD (MB/s) |
226MB/s |
Rotational Vibration @ 10-1500 Hz (rad/s) |
12.5 |
Power Consumption |
Startup Current, Typical (12V, A) |
2.0 A |
Idle Power, Average (W) |
5.5 W |
Average Operating Power (W) |
6.7 W |
Standby Mode, Typical (W) |
1.0 W |
Sleep Mode, Typical (W) |
1.0 W |
Power Supply Requirements |
+12 V and +5 V |
Environmental/Temperature |
Operating Temperature (ambient, min °C) |
0°C |
Operating Temperature (drive reported, max °C) |
65°C |
Non-operating Temperature (ambient, min °C) |
-40°C |
Non-operating Temperature (ambient, max °C) |
70°C |
Environmental/Acoustics |
Vibration, Non-operating: 10 Hz to 500 Hz (Grms) |
2.27 |
Acoustics, Idle (typical, measured in Idle 1 state) (dBA) |
28 |
Acoustics, Seek (typical) (dBA) |
30 |
Environmental/Shock |
Shock, Operating 2 ms (Read/Write) (Gs) |
70/40 Gs |
Shock, Non-operating, 1 ms and 2 ms (Gs) |
300 |
Physical |
Height (mm/in) |
26.11 mm/1.028 in |
Width (mm/in, max) |
101.85 mm/4.01 in |
Depth (mm/in, max) |
146.99 mm/5.787 in |
Weight (g/lb, typical) |
620 g/1.37 lb |
