Form Factor |
2.5 Inch |
Interface |
SATA Rev. 3.0 (6Gb/s) – with backwards compatibility to SATA Rev. 2.0 (3Gb/s) |
Capacities |
3.84TB |
NAND |
3D TLC |
Self-Encrypting Drive (SED) |
AES 256-bit Encryption |
Sequential Read/Write: (DC500R) |
3.84TB – 555MBs/520MBs |
Steady-State 4k Read/Write: (DC500R) |
3.84TB – 98,000/28,000 IOPS |
Hot-Plug Capable |
Static and Dynamic Wear Leveling |
Enterprise SMART tools |
Reliability tracking, usage statistics, life remaining, wear leveling, temperature |
Power Loss Protection |
Tantalum Capacitors |
Endurance DC500R: |
3.84TB — 3504TBW (0.5 DWPD) |
Power Consumption |
Idle: 1.56W Average: 1.6W Max Read: 1.8W Max Write: 7.5W |
Storage temperature |
-40°C ~ 85°C |
Operating temperature |
0°C ~ 70°C |
Dimensions |
69.9mm x 100mm x 7mm |
Weight |
92.34g |
Vibration operating |
2.17G Peak (7–800Hz) |
Vibration non-operating |
20G Peak (10–2000Hz) |
MTBF |
2 million hours |
Warranty/support |
Limited 5-year warranty with free technical support |
