Form factor | U.2 / 2.5" |
Capacity | 3.84TB |
Host interface | PCIe Gen 4 x4 |
Spec Compliance |
NVMe spec rev. 1.3 PCI Express base specification rev. 4.0 |
NAND flash memory | Samsung V-NAND 3-bit MLC |
Power consumption (Active/Idle) | 20W/8.5W |
Uncorrectable Bit Error Rate (UBER) | 1 sector per 10^17 bits read |
Mean Time Between Failure (MTBF) | 2,000,000 hours |
Endurance | 1 DWPD for 5 years |
Sequential read | 7,000 MB/s |
Sequential write | 3,800 MB/s |
Random read | 1,5M IOPS |
Random write | 135,000 IOPS |
Physical Dimensions | 69 x 100 x 15 mm |
Encryption Supported | TCG Opal 2.0 |
Manageability | NVMe-MI 1.0a compliant |
Operating Temperature | 0 - 70°C |
