3.84TB PM9A3 7mm, 6900 / 4100 MB/s, V-NAND 3-bit MLC, PCIe NVMe 4.0 x4, TCG Opal SSC, U.2 2.5" SSD

Quantity:
  • SKU: 15024628
  • Manufacturer: SAMSUNG
  • MPN: MZ-QL23T800
  • Availability: USUALLY SHIPS WITHIN 3-5 DAYS
Starting At
$743.61
Quantity:
Type
Interface PCIe 4.0 x4 NVMe 1.4
Series PM9A3
Application
Data Center Yes
Storage
Capacity 3.84TB
Key Features
Sequential Read Speed Up to 6,900 MB/s
Sequential Write Speed Up to 4,100 MB/s
Random Read Speed Up to 1,000,000 IOPS
Random Write Speed Up to 180,000 IOPS
Controller Samsung Elpis Controller
NAND Flash Samsung V-NAND TLC
Cache Memory Samsung Low Power SDRAM
Trim Support Yes
AES Encryption AES 256-bit Encryption
Security TCG/Opal (Class 0)
S.M.A.R.T. Support Yes
GC (Garbage Collection) Auto Garbage Collection Algorithm
WWN Support NGUID Supported
General
Power Consumption (W) Active (Read/Write): 11.0 W / 13.5 W
Idle: Max. 3.5 W
Voltage 12.0V ± 10% Allowable voltage
Reliability (MTBF) 2.0 Million Hours Reliability (MTBF)
Environmental Specs
Operating Temperature 0 - 70 °C Operating Temperature
Shock 1,500 G & 0.5 ms (Half sine)
Form Factor
Product U.2 2.5-inch 7mmT
Dimensions (W x H x D)
Product 100 X 69.85 X 6.8 (mm)
Weight
Product Max 90.0 g
Software
Management SW Samsung SSD DC Tool kit
Warranty
Product 5 Year Limited Warranty or 7,008 TBW Limited Warranty
