4K DVI/HDMI Video Splitter
2-Port 4K DVI/HDMI Video Splitter
4K DVI/HDMI Video Splitter
DVI Video Splitter simultaneously displays the same Ultra-HD 4Kx2K image from one single link DVI/HDMI video source to two displays
Supports DVI interface for crisp and clear video quality on flat panel displays
Supports video resolutions to UHD 4Kx2K 3840 x 2160
Video Input |
- Compatible with a computer or HDTV video source (satellite receiver, DVD player, etc) with DVI or HDMI output (use DVI-HD-xx-MM to connect an HDMI source).
- Multiplatform support: Windows 2000/XP/Vista/7/8/10, Windows Server 2000/2003/2008/2012, Solaris, Linux, FreeBSD, and MAC OS 9/10.
- Female DVI-I connector.
- Signal type: single link digital DVI or HDMI
- HDCP compliant
|
Video Output |
- Female DVI-I connectors.
- Signal type: single link digital DVI or HDMI.
-
- Ultra-HD4Kx2K resolutions (3840x2160 @ 24/30Hz)
- 2K Cinema (2048x1080 @ 60Hz)
- HDTV resolutions to 1080p
- Computer resolutions to 1920x1200Supported video output resolutions:
- HDCP compliant
|
Power |
- 110 to 220 VAC at 50 or 60 Hz via AC adapter. (Country-specific AC adapter included.)
|
Dimensions |
- WxDxH (in): 4.25 x 3.87 x 1.09
|
Environmental |
- Operating temperature: 32 to 100°F (0 to 38°C).
- Storage temperature: -20 to 140°F (-30 to 60°C).
- Operating and Storage Relative Humidity: 17 to 90% non-condensing RH.
|
Regulatory Approvals |
|
Warranty |
|
Cables |
- One 3-foot single link DVI-I (DVI-IS-3-MM) male-to-male cable included.
- Use DVI-HD-xx-MM to connect an HDMI source or display (not included).
|
Compatible NTI Products |
- Combine NTI's video splitters and extenders for complex applications
- Low-Cost HDMI Over Gigabit IP Extender (ST-IPHD-LC)
- Only supports HDTV resolutions to 1080p.
|
