| General |
| Brand |
Mushkin Enhanced |
| Series |
SED |
| Model |
MKNSSDSE512GB |
| Type |
7mm Internal Solid State Drive (SSD) |
| Used For |
Consumer |
| UPC |
846651029560 |
| Physical |
| Form Factor |
2.5" |
| Capacity |
512GB |
| Interface |
SATA 6Gb/s |
| Controller |
Silicon Motion SM2258/2259 |
| Height |
7mm |
| Width |
69.85mm |
| Depth |
100.45mm |
| Weight |
50g |
| Performance |
| Max Sequential Read |
Up to 560MB/s |
| Max Sequential Write |
Up to 515MB/s |
| 4KB Random Read |
Up to 93,000 |
| 4KB Random Write |
Up to 87,000 |
| Seek Time |
<0.1ms |
| TBW |
150 |
| MTBF |
1,500,000 hours |
| Features |
| Features |
MEDS (Mushkin Enhanced Data-protection Suite) ensures valuable data is protected |
| - Built-in LDPC ECC provides the most-powerful error correction method in use today |
| - Data shaping increases endurance |
| - StaticDataRefresh ensures data integrity |
| - Global wear-leveling evens program/erase counts across data blocks to extend lifespan |
| 512MB DRAM |
| Self-encrypting Drive (SED) with IEEE1667 (eDrive) and TCG Opal support |
| SLC caching accelerates burst performance |
| Supports Security Erase |
| TRIM support (OS/driver support required) |
| High-reliability NAND flash |
| S.M.A.R.T. support |
| User-upgradeable firmware |
| Temperature sensor |
| RoHS, FCC, CE |
| Power Consumption (Idle): 0.08W |
| Power Consumption (Active): 3W |
| Max sequential speeds and IOPS measured using CrystalDiskMark 6.0.2 x64 |
| Environmental |
| Operating Temperature |
0°C-70°C |
| Storage Temperature |
-40°C-85°C |
| Max Shock Resistance |
1500G |
| Power Supply |
5V DC |
