Specifications | |
---|---|
Model number1 | WD60EFAX |
Interface | SATA 6 Gb/s |
Formatted capacity2 | 6TB |
Form factor | 3.5-inch |
Advanced Format (AF) | Yes |
Native command queuing | Yes |
RoHS compliant3 | Yes |
Performance | |
Interface Transfer Rate² (read
speed) up to |
180 MB/s |
Cache (MB) | 256 |
Performance Class | 5400 RPM Class |
Reliability/Data Integrity | |
Load/unload cycles4 | 600,000 |
Non-recoverable read errors per bits read | <10 in 1014 |
MTBF (hours)5 | 1,000,000 |
Workload Rate (TB/yr) 10 | 180 |
Limited warranty (years)6 | 3 |
Power Management | |
12VDC-/+10% (A, peak) | 1,75 |
Average power requirements (W)
Read/Write Idle Standby/Sleep |
4.8 3.1 0.6 |
Environmental Specifications7 | |
Temperature (°C)
Operating8 Non-operating |
0 to 65 -40 to 70 |
Shock (Gs)
Operating (2 ms, read/write) Operating (2 ms, read) Non-operating (2 ms) |
30 65 250 |
Acoustics (dBA)9
Idle Seek (average) |
23 27 |
Physical Dimensions | |
Height (in./mm, max) | 1.028/26.1 |
Length (in./mm, max) | 5.787/147 |
Width (in./mm, ± .01 in.) | 4/101.6 |
Weight (lb/kg, ± 10%) | 1.40/0.64 |
1 Not all products may be available in all regions of the world.
2 As used for storage capacity, one megabyte (MB) = one million bytes, one gigabyte (GB) = one billion bytes, and one terabyte (TB) = one trillion bytes. Total accessible capacity varies depending on operating environment. As used for buffer or cache, one megabyte (MB) = 1,048,576 bytes. As used for transfer rate or interface, megabyte per second (MB/s) = one million bytes per second, and gigabit per second (Gb/s) = one billion bits per second. Effective maximum SATA 6 Gb/s transfer rate calculated according to the Serial ATA specification published by the SATA-IO organization as of the date of this specification sheet. Visit www. sata-io.org for details. 3 WD hard drive products manufactured and sold worldwide after June 8, 2011, meet or exceed Restriction of Hazardous Substances (RoHS) compliance requirements as mandated by the RoHS Directive 2011/65/EU. 4 Controlled unload at ambient condition. 5 Based on a typical NAS product environment under normal operating conditions. 6 The term of the limited warranty may vary by region. Visit http://support.wd.com/warranty for details. 7 No non-recoverable errors during operating tests or after non-operating tests. 8 On the base casting. 9 Sound power level. 10 Workload Rate is defined as the amount of user data transferred to or from the hard drive. Workload Rate is annualized (TB transferred X (8760 / recorded power-on hours)). Workload Rate will vary depending on your hardware and software components and configurations. |
