7.68TB DC450R 7mm, 560 / 504 MB/s, 3D TLC NAND, SATA 6Gb/s, SED, 2.5" SSD
Quantity:
- SKU: 13444888
- Manufacturer: KINGSTON
- MPN: SEDC450R/7680G
- Availability: TEMPORARILY OUT OF STOCK
Starting At
$1,044.19
7.68TB DC450R 7mm, 560 / 504 MB/s, 3D TLC NAND, SATA 6Gb/s, SED, 2.5" SSD
Kingston 7.68TB DC450R (SEDC450R/7680G). Kingston’s Data Center 450R (DC450R) is a high performance 6Gbps SATA SSD with 3D TLC NAND, designed for Read Centric application workloads. This streamlined SSD delivers on performance while providing exceptional I/O and latency predictability, a requirement now amongst Data Center Class SSDs. Built to Kingston’s strict QoS requirements, the DC450R is designed to ensure performance consistency over a wide range of read intensive and read caching workloads.
Read-Centric Applications
- Performance consistency in Edge Computing and CDN applications.
Reduce application latencies
- Database and web-based applications leverage predictable I/O and latency performance.
Data Integrity Protection
- ECC protection with advanced read/disturb management safeguards against data corruption; end-to-end data protection.
Strategically Optimized
- Focused feature set enables data centers to select the most cost effective SSD for their workload(s).
| Form Factor | 2.5" |
| Interface | SATA Rev. 3.0 (6Gb/s) – With backwards compatibility to SATA Rev. 2.0 (3Gb/s) |
| Capacities | 7.68TB |
| NAND | 3D TLC |
| Self-Encrypting Drive (SED) | XTS-AES 256-bit Encryption |
| Sequential Read/Write | 7.68TB – 560MBs/504MBs |
| Steady-State 4k Read/Write | 7.68TB – 99,000/19,000 IOPS |
| Quality of Service (Latency) | TYP Read/Write: <500 µs / <2 ms |
| Hot-Plug Capable | Yes |
| Static and Dynamic Wear Leveling | Yes |
| Power Loss Protection (Power Caps) | No |
| Enterprise SMART tools | Reliability tracking, usage statistics, SSD life remaining, wear leveling, temperature |
| Endurance DC450R | 7.68TB —5063TB (0.3 DWPD/5yrs) |
| Power Consumption | 7.68TB: Idle: 1.38W Average Read: 1.5W Average Write: 4W Max Read: 1.5W Max Write: 5.5W |
| Storage temperature | -40°C ~ 85°C |
| Operating temperature | 0°C ~ 70°C |
| Dimensions | 69.9mm x 100mm x 7mm |
| Weight | 92.34g |
| Vibration operating | 2.17G Peak (7–800Hz) |
| Vibration non-operating | 20G Peak (10–2000Hz) |
| MTBF | 2 million hours |
| Warranty/support | Limited 5-year warranty with free technical support |
