| Form factor |
U.2, 2.5” x 15mm |
| Interface |
PCIe NVMe Gen3 x4 |
|
Capacities2
|
960GB |
| NAND |
3D TLC |
| Sequential read/write |
960GB – 3,100 / 1,700MB/s |
| Steady-state 4k read/write |
960GB – 440,000/150,000 IOPS |
|
Latency Quality of Service (QoS)3,4,5
|
99.9 - read/write: <110 µs / <206 µs |
| Static and dynamic wear levelling |
Yes |
| Power loss protection (power caps) |
Yes |
| Namespace management support |
Yes - 64 namespaces supported |
| Enterprise diagnostics |
Telemetry, media wear, temperature, health and error logs, etc. |
| Endurance |
960GB – (1 DWPD/5yrs)6 |
| Power consumption |
960GB – Idle: 6.30W Average read: 6.21W Average write: 11.40W Max read: 6.60W Max write: 12.24W |
| Operating temperature |
0°C ~ 70°C |
| Dimensions |
100.09mm x 69.84mm x 14.75mm |
| Weight |
960GB – 145g |
| Vibration operating |
2.17G peak (7–800Hz) |
| Vibration non-operating |
20G peak (10–2000Hz) |
| MTBF |
2 million hours |
|
Warranty/support1
|
Limited 5-year warranty with free technical support |
-
Limited warranty based on 5 years or when the usage of an NVME SSD as indicated by Kingston’s implementation of the Health attribute “Percentage Used” reaches or exceeds a normalized value of
one hundred (100) as indicated by the Kingston SSD Manager. For NVMe SSDs, a new unused product will show a Percentage Used value of 0, whereas a product that reaches it warranty limit will show a Percentage
Used value of greater than or equal to one hundred (100).
-
Some of the listed capacity on a Flash storage device is used for formatting and other functions and thus is not available for data storage. As such, the actual available capacity for data storage is less than
what is listed on the products. For more information, go to Kingston's Flash Memory Guide.
-
Workload based on FIO, random 4KB QD=1 workload, measured as the time taken for 99.9% of commands to finish the round-trip from host to drive and to host.
-
Measurement taken once the workload has reached steady state but including all background activities required for normal operation and data reliability.
-
Based on 1920GB capacity.
-
Drives Writes Per Day (DWPD) derived from the JEDEC Enterprise Workload (JESD219A).
|
