A19, 110mm Height, 105W TDP, Copper/Aluminum CPU Cooler

Quantity:
  • SKU: 13588530
  • Manufacturer: DYNATRON
  • MPN: A19
  • Availability: USUALLY SHIPS WITHIN 1-3 WEEKS
Starting At
$30.01
Quantity:
A19, 110mm Height, 105W TDP, Copper/Aluminum CPU Cooler
Recommend for AMD® Ryzen Processor, Socket AM4, and AM5, 80x80x38mm Powerful fan with PWM function, HCC (Heatpipe Contact CPU) technology, Active Cooler for 3U Server & Up, Workstation, Support CPU Power 105 Watts Heat Dissipation.
CPU Support

AMD® Ryzen

CPU Socket

AM4/AM5

Solution

3U Server and up, Workstation

Dimensions

107.5 x 78 x 110 mm

Weight

600 g

Material

Aluminum Stacked Fin with Heat Pipes directly contact CPU

Fan Dimension

80 x 80 x 38 mm

Speed

At Duty Cycle 20%: 1000±10% RPM
At Duty Cycle 50%: 2000±10% RPM
At Duty Cycle 100%: 3800 RPM

Bearing

Double Ball

Rated Voltage

12V

Power

At Duty Cycle 20%: 2.2 W
At Duty Cycle 50%: 3.6 W
At Duty Cycle 100%: 7.9 W

Air Flow

At Duty Cycle 20%: 13.8 CFM
At Duty Cycle 50%: 30.78 CFM
At Duty Cycle 100%: 65.4 CFM

Noise Level

At Duty Cycle 20%: 16.0 dBA
At Duty Cycle 50%: 31.5 dBA
At Duty Cycle 100%: 43.4 dBA

Air Pressure

At Duty Cycle 20%: 0.42 mm-H2O
At Duty Cycle 50%: 2.45 mm-H2O
At Duty Cycle 100%: 9.75 mm-H2O

Lead Wire Pin Out

Pin1- (-)
Pin2- (+)
Pin3- (Techometer/Signal output)
Pin4- (PWM)

*All product specifications and product images are subject to change without notice.
