Main Specifications |
Device Type |
SAS Controller |
Form Factor |
Low Profile |
Interface |
x8 PCIe Gen 4.0 |
Dimensions (WxDxH) |
Height: 2.7 x Length: 6.6 in |
Storage Controller |
RAID Level |
RAID 0, 1, 5, 6, 10, 50, 60 |
Onboard Memory/Cache |
8GB DDR4 onboard cache memory – 2666MHz |
Data Transfer Rate |
Supports 3.0, 6.0 and 12.0 Gb/s SAS data transfer rates and 3.0 & 6.0 Gb SATA |
Expansion / Connectivity |
Interface / Ports |
8 internal SAS3 ports - 1x SlimSAS x8 black (100-Ohm) connector |
Software / System Requirements |
OS Supports |
Windows/Linux |
Miscellaneous |
Features |
Supports: MCTP over PCIe, Supports advanced software Encryption - included, Supports MegaRAID Storage Manager SW and secure boot |
Compatible Servers |
AS-1114S-WN10RT, AS-2024S-TR, AS-2124GQ-NART, SYS-110P-WTR, SYS-120U-TNR, SYS-220BT-DNTR, SYS-220U-MTNR, SYS-220U-TNR, SYS-420GP-TNR, SYS-510P-M, SYS-510P-WTR, SYS-520P-WTR, SSG-6049SP-DE1CR90, SSG-6049SP-E1CR60,
SYS-620BT-DNTR, SSG-620P-ACR12H, SYS-620U-TNR, SYS-740GP-TNRT, SYS-F610P2-RTN, SYS-F620P3-RTBN
|
Compatible Motherboards |
H12DSU-iN, H12DSU-iNR, H12SSFF-AN6, M12SWA-TF, X11SCZ-F, X12DPT-PT6, X12SPL-F, X12SPL-LN4F, X12SPO-F |
Compliant Standards |
RoHS Compliant 6/6, Pb Free |
