AP-3UMK12P868, 80 PLUS Platinum, 1200W, Single, 3U Power Supply
- SKU: 19505547
- Manufacturer: ATHENA POWER
- MPN: AP-3UMK12P868
- Availability: USUALLY SHIPS WITHIN 1-3 WEEKS
Price
$405.95
- 1200W continuous power output for high-performance systems
- 80 PLUS Platinum efficiency – up to 92% under typical loads
- ATX 3.1 & PCIe 5.0 compliant for future-ready compatibility
- 12V-2x6 (H++) GPU connector for improved current handling and thermal safety
- Dual smart fans with thermal speed control for efficient, quiet cooling
- Universal AC input (100–240V) with active PFC for global use
- Low ripple and noise output – ideal for mission-critical and A/V environments
- IEC/UL 62368-1 certified for international safety standards
- Supports ATX 20/24-pin, EPS-12V, PCIe, SATA, and Molex connections
- 3U form factor – perfect for rackmount servers, workstations, and custom builds
| Model | AP-3UMK12P868 | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Product Category | 3U | ||||||||||||
| Output Power | 1200 Watts | ||||||||||||
| Input Votage | 100 ~ 264 Volts AC | ||||||||||||
| Frequency | 47/63 Hz | ||||||||||||
| Temperature Range | Operating: 0°C ~ +50°C on Full Load; Storage & Shipping: -20°C ~ +80°C | ||||||||||||
| MTBF | 100,000 Hours on Maximum Load at +25°C | ||||||||||||
| Rise time | Less than 20 ms | ||||||||||||
| Hold-up Time | 17 ms Minimum at Nominal Input Voltage | ||||||||||||
| Output |
|
||||||||||||
| Connectors |
ATX Connector 24 (20+4) Pin x 1
12V-2x6(H++) 600W Connector x 1
EPS-12V 8 Pin x 1 + 8 Pin (4+4) x 1
PCIE 6+2 Pin x 2
SATA 15 Pin x 8
SATA 15 Pin x 8
Molex 4 Pin x 2
|
||||||||||||
| Dimension | 3U (D x W x H) 200 x 115.5 x 86.4 mm / 7.84 x 4.5 x 3.4 in | ||||||||||||
| Weight | 5.00lb | ||||||||||||
| Warranty | 5 Year Manufacture Limited Warranty |
