- Capacity: 900 VA / 480 W
- Topology: Line Interactive
- Waveform: Simulated Sine Wave
- Output: 120 VAC ± 5%
- Plug type & cord: NEMA 5-15P, 5 ft. cord
- Outlets: 12 (6 surge, 6 surge + battery backup)
- Data line protection: Telephone
- Management software: PowerPanel® Personal Edition
- Warranty: 3 year
General | |
UPS Topology | Line Interactive |
Energy Saving | GreenPower UPS™ Bypass |
Input | |
Voltage | 120 VAC |
Frequency Range | 60 Hz ± 3 Hz |
Plug Type | NEMA 5-15P |
Plug Style | Right Angle, 45° Offset Right |
Cord Length | 5 ft |
Output | |
VA | 900 VA |
Watts | 480 W |
Automatic Voltage Regulation | Yes |
On Battery Voltage | 120 VAC ± 5% |
On Battery Frequency | 60 Hz ± 1% |
On Battery Waveform | Simulated Sine Wave |
Outlets – Total | 12 |
Outlets – Battery & Surge Protected | 6 |
Outlets – Surge-Only Protected | 6 |
Transfer Time | 4 ms |
Outlet Type | NEMA 5-15R |
Overload Protection |
Internal Circuitry Limiting Circuit Breaker |
Rated Power Factor | 0.53 |
Battery | |
Runtime at Half Load | 10 minutes |
Runtime at Full Load | 2 minutes |
Battery Type | Sealed Lead-Acid |
Battery Size | 12V/9Ah |
Battery Quantity | 1 |
Hot-Swappable | No |
User Replaceable | Yes |
Replacement Battery Cartridge | RB1290A |
Replacement Battery Cartridge Quantity | 1 |
Typical Recharge Time | 8 hours |
Surge Protection & Filtering | |
Surge Suppression | 1,030 J |
Phone RJ11 | 1-In, 2-Out |
EMI/RFI Filtration | Yes |
Management & Communications | |
HID Compliant USB Port | Yes |
Cable Management | USB Cable |
LED Indicators |
Power On Wiring Fault |
Audible Alarms |
On Battery Low Battery Overload Fault |
Software | PowerPanel® Personal Edition |
Physical | |
Form Factor | Compact |
Keyhole Mounting Slots | Yes |
Dimensions – W×H×D (in) | 12.2 × 7 × 3.5 inches |
Weight (lbs) | 14.04 lbs |
Environmental | |
Operating Temperature | 32 °F – 104 °F (0 °C – 40 °C) |
Operating Humidity | 0 – 90% (non-condensing) |
Storage Temperature | 5 – 113 °F (-15 – 45 °C) |
Maximum Operating Elevation | 6,562 ft (2,000 m) |
Maximum Storage Elevation | 50,000 ft (15,000 m) |
Certifications | |
Safety |
UL1778 cUL 107.3 FCC DOC Class B |
Environmental | RoHS Compliant |
Warranty | |
Product Warranty | 3 Years Limited |
Connected Equipment Guarantee | Lifetime |
