- 15.5mm thick slim fan, ideal fan for space-limited builds
- Distinctive “Shark Force” fan blade design with high air pressure enables quick heat dissipation through radiators or heatsinks
- Wide 0~1,700 RPM speed range via PWM control
- Modular cable design simplifies connection and management of cables
- Engineered to also be an effective exhaust fan for transporting large volume of heat out of most systems
- All-copper Fluid Dynamic Bearing (FDB) offers superior performance with long lifespan.
- Utilizes standard ARGB 4-1 pin for compatibility, displays any color combination by use of an addressable RGB controller or capable motherboard
Model No. | SST-AS140B-ARGB |
Material | Polycarbonate fan blades, PBT frame |
Color | Translucent fan blades, black frame |
Bearing | All copper FDB |
Connectors | 4 pin PWM connector + 4-1 pin ARGB (5V LED) |
Rated Voltage | 12V |
Starting Voltage | 6V |
Rated Current |
Fan:0.27A LED:0.54A |
Rated Power |
Fan:3.24W LED:2.7W |
Speed | 0 ~ 1,700 RPM |
Airflow | 0 ~ 82 CFM |
Static Pressure | 0 ~ 2mmH2O |
Noise Level | 0 ~ 33 dBA |
Number of poles | 6 |
Dimension |
140mm (W) x 15.5mm (H) x 140mm (D) 5.51" (W) x 0.61" (H) x 5.51" (D) |
Weight | 136g |
Cable length |
[Parent PWM cable] 20mm [4-pin PWM cable] 480mm [Parent ARGB cable] 20mm [ARGB cable] 400mm female to 100mm male Y-splitter connectors |
Extra |
[Varying length daisy-chain PWM cable] 125mm & 50mm [Varying length daisy-chain ARGB cable] 125mm & 50mm |
