Product SKU | A-U50-P00G-PQ-G |
Total electrical card load | 75W |
Thermal cooling solution | Passive |
Weight | 300g – 325g |
Form factor | Half height, half length |
Network interface | 1x QSFP28 (100 GbE) |
Network clock precision | IEEE 1588 |
PCIe interface | Gen3 x16, Gen4 x8, CCIX |
HBM2 total capacity | 8 GB |
HBM2 bandwidth | 316 GB/s |
Look-up tables (LUTs) | 872K |
Registers | 1,743K |
DSP slices | 5,952 |
Max. Dist. RAM | 24.6 Mb |
36 Kb block RAM | 1344 (47.3 Mb) |
288 Kb UltraRAM | 640 (180.0 Mb) |
GTY transceivers | 20 |
VCCINT supported | VNOM (0.85V) |
Vitis™ Development Enviroment | Yes |
Vitis platform | Gen3 x16 XDMA, Gen3 x4 XDMA |
Vivado Design Suite | Yes |
Target workloads |
Fintech, video, database, and computational storage |
Qualified for deployment | Yes |
