- 46mm-wide heatsink eliminates interference with memory modules.
- 7-bladed high-performance 120mm PWM controlled fan
- Spring screw mounting design enables straightforward installation on both Intel and AMD platforms [1]
- Four Ø6mm copper heat-pipes and aluminum fins for excellent heat conducting efficiency
- Anti-vibrational rubber pads are included to minimize vibration-induced noises
- Heat-pipe direct contact (HDC) technology
| Model No. | SST- ARV120B |
| Material | Copper heat-pipes with aluminum fins |
| Application |
Intel LGA 1700/1851 AMD Socket AM4/AM5 * * Please use the original backplate on your AMD platform motherboard |
| Fan | |
| Dimension |
120mm (W) x 120mm (H) x 25mm (D) 4.72" (W) x 4.72" (H) x 0.98" (D) |
| Speed | 800 ~ 2,000 RPM |
| Noise level | 36.2 dBA |
| Rated Voltage | 12V |
| Rated Current | 0.25A |
| Max airflow | 71.82 CFM |
| Max air pressure | 3.15mmH2O |
| Connector | 4 Pin PWM |
| Bearing | Hydraulic bearing |
| MTTF | 30,000 hours |
| Dimension |
123mm (W) x 153mm (H) x 78mm (D) 4.84" (W) x 6.02" (H) x 3.07" (D) |
| Net weight | 615g |
