| Compliant Standards |
Bluetooth 5.4, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11az, IEEE 802.11b, IEEE 802.11be, IEEE
802.11d, IEEE 802.11e, IEEE 802.11g, IEEE 802.11h, IEEE 802.11i, IEEE 802.11k, IEEE 802.11n, IEEE 802.11r,
IEEE 802.11u, IEEE 802.11v, IEEE 802.11w, Wi-Fi CERTIFIED 6, Wi-Fi CERTIFIED 6E, Wi-Fi CERTIFIED 7
|
| Connectivity Technology |
Wireless |
| Data Link Protocols |
Bluetooth 5.4, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6E), IEEE 802.11b, IEEE 802.11be (Wi-Fi 7),
IEEE 802.11g, IEEE 802.11n
|
| Data Transfer Rate |
5.8 GBps |
| Features |
2x2 MU-MIMO technology, 802.1x authentication, Protected management frames, Wi-Fi Agile Multiband, Wi-Fi
Direct, Wi-Fi Multimedia (WMM) support, Wireless radio enable/disable, WMM Power Save
|
| Form Factor |
Plug-In Card |
| Host Interface |
M.2 2230 |
| Network Band |
2.4 GHz, 5 GHz, 6 GHz |
| Product Type |
Network adapter |
| Spread Spectrum Method |
OFDMA |
| Encryption |
128-bit AES-CCMP, 256-bit AES-GCMP, EAP-AKA, EAP-MSCHAPv2, EAP-SIM, EAP-TLS, EAP-TTLS, MSCHAPv2, PEAP, WPA2,
WPA3-Enterprise, WPA3-Personal
|
| Line Coding Format |
1024 QAM, 16 QAM, 256 QAM, 4096 QAM, 64 QAM, BPSK, OFDMA, QPSK |
| Max Operating Temperature |
176 degree Fahrenheit |
| Min Operating Temperature |
32 degree Fahrenheit |
| Operating Humidity |
50 - 90% RH (non-condensing) |
| Operating System Required |
Linux, Windows 10, Windows 11 |
