BPN-124K-SA Trayless 5.25" to 4x 2.5" SATA 6 Gbps HDD SSD Hot-swap Rack

  • SKU: 8552694
  • Manufacturer: ISTARUSA
  • MPN: BPN-124K-SA
  • Availability: USUALLY SHIPS WITHIN 1-3 WEEKS
Starting At
BPN-124K-SA Trayless 5.25" to 4x 2.5" SATA 6 Gbps HDD SSD Hot-swap Rack

The 2.5" Disk Array BPN-124K-SA to be set up in various configurations as RAID 0, RAID 1, RAID 5 or JBOD as individual drives. The unit is featured with HDD hot-swappable, which can remove or add HDDs to the system without turning off the computers. The back plane connection include SATA connectors and each drive is equipped with power and drive activity LEDs.

  • Plug & Play, Hot Swappable
  • LED for Power & HDD Activity
  • High Performance Transfer Rate up to 6.0 Gb/s
  • Support 4 x 2.5" SATA I/II/III HDDs
  • Constructed with metal body, plastic ABS front panel, and metal latch for heavy use
  • Support 2.5" HDD/SSD thickness from 9.5 to 12.5mm
Model Number BPN-124K-SA
RoHS Compliance Version Yes
Standard Drive Bays Hotswap 2.5": 4
5.25" Drives: 1
Hotswap HDD Type: 2.5" SATA I/II/III
Indicators Power On: solid blue/ HDD Access: blue blinking
Security Key Lock
Material of Handle Plastic with Metal Latch
Material of Main Chassis SECC Steel
Color of Main Chassis Black
Dimensions (WxHxD) 5.83" x 1.65" x 5.59"
148.1 mm x 41.9 mm x 142.0 mm
Notes - not compatible with D Storm chassis on the right 5.25" drive bays when facing the chassis
